NTE Cross-Reference Component List
Last Update: 20240605
Easy to use: Just start typing your part number to filter the list.
Part | NTE Part # | Description |
---|---|---|
OA91(A) | NTE109 | Glass Germanium Diode |
OA95 | NTE109 | Glass Germanium Diode |
OA-95 | NTE177 | General Purpose Silicon Rectifier |
1N34 | NTE109 | Glass Germanium Diode, 80V 60mA |
1N48 | ---- | Gold Bonded Germanium Diode (similar to the 1N34A) |
1N60 | NTE110A | Glass Germanium Diode, 30V 150mA |
1N82(A,D,G) | NTE112 | Silicon Small Signal Schottky Diode |
1N270 | NTE109 | Glass Germanium Diode, 80V 60mA |
1N456(A) | NTE177 | General Purpose Silicon Rectifier, 150V 250mA |
1N457(A,M) | NTE177 | General Purpose Silicon Rectifier, 150V 250mA |
1N725(A) | NTE5035A | ZENER Diode, 30.0v 0.5W |
1N743(A,B) | NTE5056A | ZENER Diode, 160.0v 0.5W |
1N744(A) | NTE5058A | ZENER Diode, 180.0v 0.5W |
1N745(A) | NTE5060A | ZENER Diode, 200.0v 0.5W |
1N746(A) | NTE5005A | ZENER Diode, 3.3v 0.5W |
1N747(A) | NTE5006A | ZENER Diode, 3.6v 0.5W |
1N748(A) | NTE5007A | ZENER Diode, 3.9v 0.5W |
1N749(A) | NTE5008A | ZENER Diode, 4.3v 0.5W |
1N750(A) | NTE5009A | ZENER Diode, 4.7v 0.5W |
1N751(A) | NTE5010A | ZENER Diode, 5.1v 0.5W |
1N752(A) | NTE5011A | ZENER Diode, 5.6v, 0.5W |
1N753(A) | NTE5013A | ZENER Diode, 6.2v, 0.5W |
1N754(A) | NTE5014A | ZENER Diode, 6.8v, 0.5W |
1N755(A) | NTE5015A | ZENER Diode, 7.5v, 0.5W |
1N756(A) | NTE5016A | ZENER Diode, 8.2v, 0.5W |
1N757(A) | NTE5018A | ZENER Diode, 9.1v, 0.5W |
1N758(A) | NTE5019A | ZENER Diode, 10.0v, 0.5W |
1N759(A) | NTE5021A | ZENER Diode, 12.0v, 0.5W |
1N760 | NTE177 | General Purpose Silicon Rectifier, 200V 1A |
1N762 | NTE5012A | ZENER Diode, 6.0v, 0.5W |
1N764 | NTE5073A | ZENER Diode, 8.7v, 0.5W |
1N766 | NTE5022A | ZENER Diode, 13.0v, 0.5W |
1N767(A) | NTE5025A | ZENER Diode, 16.0v, 0.5W |
1N768(A) | NTE5028A | ZENER Diode, 19.0v, 0.5W |
1N769 | NTE5081A | ZENER Diode, 24.0v, 1.0W |
1N770 | NTE109 | Germanium Diode, Fast Switching, General Purpose |
1N914 | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch, 100V 300mA |
1N916(A,B) | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch, 100V 2A |
1N1519(A) | NTE5069A | Zener Diode, 4.7V 1W |
1N1612 | NTE5850 | Silicon Power Rectifier Diode, 6A, DO4 |
1N1612R | NTE5870 | Silicon Power Rectifier Diode, 12A, DO4 |
1N3022 | NTE142A | Zener Diode, 12V 1W |
1N3209 | NTE5942 | Silicon Power Rectifier Diode, 15 Amp, 100v |
1N3754 | NTE5801 | Silicon Rectifier, Axial Lead, Standard Recovery, 3A DO27 |
1N3880(A,M) | NTE5818 | Silicon Power Rectifier, Fast Recovery 12A 200V Cathode to Case DO4 |
1N3880R | NTE5819 | Silicon Power Rectifier, Fast Recovery 12A 200V Anode to Case DO4 |
1N3899 | NTE6006 | Silicon Power Rectifier Diode, 40 Amp, 200v |
1N4001 | NTE116 | Silicon Rectifier 50v 1A |
1N4002 | NTE116 | Silicon Rectifier 100v 1A |
1N4003 | NTE116 | Silicon Rectifier 200v 1A |
1N4004 | NTE116 | Silicon Rectifier 400v 1A |
1N4005 | NTE116 | Silicon Rectifier 600v 1A |
1N4006 | NTE125 | Silicon Rectifier 800v 1A |
1N4007 | NTE125 | Silicon Rectifier 1000v 1A |
1N4148 | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch, 100V 300mA |
1N4150(V) | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch, 100V 500mA |
1N4728 | NTE5066A | ZENER 3.3v1W 200mA |
1N4730 | NTE5067A | ZENER 3.9v1W 200mA |
1N4732(A) | NTE5069A | ZENER 4.7v 1W 200mA |
1N4733 | NTE135A | ZENER 5.1v1W 200mA |
1N4735 | NTE137A | ZENER 6.2v 1W 200mA |
1N4736(A) | NTE5071A | ZENER 6.8v1W 200mA |
1N4737(A) | NTE138A | ZENER 7.5V1W 200mA |
1N4738 | NTE5072A | ZENER 8.2v1W 200mA |
1N4739 | NTE139A | ZENER 9.1v1W 200mA |
1N4740 | NTE140A | ZENER 10.0V1W 200MA |
1N4741(A) | NTE5074A | ZENER11.0v1W 200mA |
1N4742 | NTE142A | ZENER12.0v1W 200mA |
1N4743 | NTE143A | ZENER 13.0v1W 200mA |
1N4744(A) | NTE145A | ZENER15.0v1W 200mA Vf 1.2V |
1N4745(A) | NTE5075A | ZENER 16.0v 1W 200mA |
1N4746 | NTE5077A | ZENER18.0v1W 200mA |
1N4747 | NTE5135A | ZENER20.0v1W 200mA |
1N4748 | NTE5080A | ZENER22.0v1W 200mA |
1N4749 | NTE5081A | ZENER24.0V1W 200mA |
1N4753(A) | NTE5085A | ZENER 36.0v 1W 200mA |
1N4754(A) | NTE5086A | ZENER 39.0v 1W 200mA |
1N4933 | 1N4933 | Silicon Rectifier, General Purpose, Fast Recovery Diodes 50V |
1N4934 | NTE552 | Silicon Rectifier, General Purpose, Fast Recovery Diodes 100V |
1N4935 | NTE552 | Silicon Rectifier, General Purpose, Fast Recovery Diodes 200V |
1N4936 | NTE552 | Silicon Rectifier, General Purpose, Fast Recovery Diodes 400V |
1N4937 | NTE552 | Silicon Rectifier, General Purpose, Fast Recovery Diodes 600V |
1N4942 | NTE574 | Silicon Rectifier, General Purpose, Fast Recovery Diodes 400V 1A |
1N5233B | NTE5012A | Zener Diode, 6.0v 0.5W, ±5% Tolerance |
1N5338B | NTE5116A | Zener Diode, 5.1v 5W |
1N5350(A,B) | NTE5128A | Zener Diode, 13.0v 5W |
1N5364B | NTE5142A | Zener Diode, 33.0v 5W |
1N5400(G) | NTE5800 | Axial Lead Standard Recovery, Silicon Rectifier, 50v 3A, DO27 |
1N5401(G) | NTE5801 | Standard Recovery, Silicon Rectifiers, 100v 3A, DO27 |
1N5402(G) | NTE5802 | Standard Recovery, Silicon Rectifiers, 200v 3A, DO27 |
1N5404 | NTE5804 | Standard Recovery, Silicon Rectifiers, 400v 3A, DO27 |
1N5408 | NTE5809 | Silicon Rectifier, 1000v 3A |
1N5711 | NTE583 | Silicon Rectifier Diode, Schottky, RF Switch DO-35 Package |
1N5817(G) | NTE585 | Schottky Barrier, Fast Switching 20V 1A 1.25W+ |
1N5818(G) | NTE585 | Schottky Barrier, Fast Switching 30V 1A 1.25W + |
1N5819 | NTE585 | Schottky Barrier, Fast Switching 40V 1A 1.25W+ |
1N5820 | NTE586 | Schottky Barrier, Fast Switching 20V 3A 3.6W + |
1N5821 | NTE586 | Schottky Barrier, Fast Switching 30V 3A 3.6W + |
1N5822(B) | NTE586 | Schottky Barrier, Fast Switching 40V 3A 3.6W+ |
1N5838B | NTE5001A | Zener Diode, 2.5v 0.5W |
1N6263 | NTE583 | Silicon Rectifier Diode Schottky, RF Switch |
IRF9540 | NTE2371 | MOSFET P-Channel, Enhancement Mode, High Speed Switch |
1S1588 | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch |
1S2074 | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch |
1SS99 | NTE112 | Silicon Small Signal Schottky Diode |
1SS119 | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch |
2N158 | NTE121 | PNP Germanium Transistor, Audio Frequency Power Amp. |
2N256 | NTE104 | PNP Germanium Transistor, Audio Frequency Power Amp. |
2N337 | NTE123 | NPN Silicon Transistor, General Purpose Audio Amplifier, Switch |
2N404 | NTE102 | PNP Germanium Complementary Transistor, Power Output, Power |
2N554 | NTE121 | PNP Germanium Transistor, Audio Frequency Power Amp. |
2N700 | NTE160 | PNP Germanium Transistor, RF-IF Amp, FM Mixer Osc. |
2N702 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N918(A) | NTE161 | NPN Silicon Transistor, VHF–UHF Amplifier, Mixer/Osc |
2N930 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N1038 | NTE176 | PNP Germanium Transistor, Audio Power Amp. |
2N1302 | NTE101 | NPN Germanium Complementary Transistor, Oscillator, Mixer for AM Radio, Medium Speed Switch |
2N1380 | NTE102 | NPN Germanium Complementary Transistor, Power Output, Driver |
2N1613(A,L,S) | NTE128 | NPN Silicon Complementary Transistor, Audio Output, Video, Driver 140v |
2N1711(A,B,L) | NTE128 | NPN Silicon Complementary Transistor, Audio Output, Video, Driver 140v |
2N2148 | NTE121 | PNP Germanium Transistor, Audio Frequency Power Amp. |
2N2188 | NTE160 | PNP Germanium Transistor, RF-IF Amp, FM Mixer OSC. |
2N2219(A) | NTE123 | NPN Silicon Transistor, General Purpose Audio Amplifier, Switch |
2N2222(A,B) | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N2907(A) | NTE159M | PNP Silicon Complementary Transistor, General Purpose |
2N2369(A) | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N2430 | NTE103A | PNP Germanium Complementary Transistor, Medium Power Amp |
2N2646 | NTE6401 | N-Channel, Uni-junction Transistor |
2N2647 | NTE6409 | Uni-junction Transistor |
2N2712 | NTE85 | NPN Silicon Transistor, General Purpose Amp. |
2N2712Blue | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amp. |
2N2905(A) | NTE129 | PNP Silicon Complementary Transistor, Audio Output, Video, Driver 80v |
2N2905AS(S) | NTE159 | PNP Silicon Complementary Transistor, Audio Amp., Switch |
2N2907(A) | NTE159M | PNP Silicon Complementary Transistor, General Purpose |
2N3019 | NTE128 | NPN Silicon Complementary Transistor, General Purpose |
2N3053(A,S) | NTE128 | NPN Silicon Complementary Transistor, Audio Output, Video, Driver 140v |
2N3055 | NTE130 | NPN Power Transistor, 100V 15A (usually needs a Heat Sink) (TO-3, or use TIP3055) |
2N3302 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N3391(A) | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
2N3392 | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
2N3417 | NTE192A | NPN Silicon Complementary Transistor, Audio Power Output |
2N3440 | NTE396 | NPN Silicon Transistor, Power Amplifier & High Speed Switch |
2N3528 | NTE5455 | Silicon Controlled Rectifier, Sensitive Gate, 200V 4A |
2N3553 | NTE473 | NPN Silicon Transistor, RF Power Driver |
2N3563 | NTE108 | NPN Silicon Transistor, High Frequency Amplifier |
2N3565 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N3553 | NTE473 | NPN Silicon Transistor, RF Power Driver |
2N3611 | NTE121 | PNP Germanium Transistor, Audio Frequency Power AMP |
2N3638(A) | NTE129 | PNP Silicon Complementary Transistor, Audio Output, Video, Driver 80v |
2N3646 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
2N3663 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
2N3702 | NTE290A | PNP Silicon Complementary Transistor, Audio Power Amplifier |
2N3704(A) | NTE85 | NPN General Purpose Amplifier |
2N3706 | NTE85 | NPN General Purpose Amplifier |
2N3707 | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
2N3708 | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
2N3711 | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
2N3772(C) | NTE181 | NPN Silicon Power Transistor, High Power Audio Amplifier |
2N3819 | NTE312 | General-Purpose N-Channel FET |
2N3866(A) | NTE311 | NPN Silicon Transistor, Frequency Multiplier, Driver, VHF/UHF, 30V 400mA 5W |
2N3886 | NTE5580 | SCR 200V 275A |
2N3903 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
2N3905 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
2N3904 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch, 40V 200mA |
2N3906 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch, 40V 200mA |
2N4250 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
2N4254 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
2N4258 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
2N4258A | NTE106 | PNP Silicon Transistor, Switching Transistor |
2N4392 | NTE466 | Silicon N–Channel J-FET Transistor, Chopper, High Speed Switch |
2N4400 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
2N4401 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
2N4403 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
2N4427 | NTE346 | NPN Silicon Transistor, RF POWER, 20V 400mA 1Watt to 3.5W |
2N4441 | NTE5442 | SCR 50V 8A |
2N4856 | NTE466 | Silicon N-Channel JFET |
2N4870 | NTE6410 | UJT Unijunction Transistor, 30V 50mA |
2N4871 | NTE6410 | UJT Unijunction Transistor, 30V 50mA |
2N4891 | NTE6409 | UJT Unijunction Transistor, 30V 50mA |
2N4900 | NTE218 | PNP Silicon Transistor, Audio Power Output |
2N4921 | NTE184 | NPN Silicon Complementary Transistor, Audio Power Amp, Switch |
2N4923 | NTE184 | NPN Silicon Complementary Transistor, Audio Power Amp, Switch |
2N4954 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
2N5060 | NTE5400 | Silicon Controlled Rectifier (SCR), 30v 0.8 Amp Sensitive Gate, TO92 |
2N5061 | NTE5401 | Silicon Controlled Rectifier (SCR), 60v 0.8 Amp Sensitive Gate, TO92 |
2N5064 | NTE5404 | Silicon Controlled Rectifier (SCR), 200v 0.8 Amp Sensitive Gate, TO92 |
2N5109 | NTE278 | NPN Silicon Transistor, Broadband RF Amp. |
2N5129 | NTE123 | NPN Silicon Transistor, General Purpose Audio Amp, Switch |
2N5139 | NTE159 | PNP Silicon Transistor, Audio AMP, Switch |
2N5139A | NTE193 | PNP Silicon Complementary Transistor, Audio Power Output |
2N5179 | NTE316 | NPN Silicon Transistor, High Gain, Low Noise Amp |
2N5305(A) | NTE172A | NPN Silicon Transistor, Darlington Preamp, Medium Speed Switch |
2N5401 | NTE288 | PNP Silicon Transistor, Audio Power Amplifier |
2N5458 | NTE457 | Silicon N–Channel JFET Transistor, General Purpose Amp, Switch (or use MPF102) |
2N5460 | NTE326 | Silicon P-Channel JFET Transistor, General Purpose, AF Amp. |
2N5484 | NTE451 | Silicon N–Channel JFET Transistor, VHF/UHF Amplifier |
2N5485 | NTE451 | Silicon N–Channel JFET Transistor, VHF/UHF Amplifier |
2N5486 | NTE451 | Silicon N–Channel JFET Transistor, VHF/UHF Amplifier |
2N5088 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
2N5550 | NTE194 | NPN Silicon Transistor, Audio Power Amplifier |
2N5551 | NTE194 | NPN Silicon Transistor, Audio Power Amplifier |
2N6027 | NTE6402 | Programmable Unijunction Transistor (PUT) (sometime labeled as an SCR) |
2N6057 | NTE247 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
2N6058 | NTE247 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
2N6059 | NTE247 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
2N6071 | NTE5603 | TRIAC 200V 4A |
2N6075 | NTE5607 | TRIAC 600V 4A (or use C106E) |
2N6283 | NTE251 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
2N6284 | NTE251 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
2N6388 | NTE263 | NPN Silicon Complementary Transistor, Darlington Power Amplifier, 10AMPS, TO220 |
2N7000 | NTE491 | MOSFET, N−Ch, Enhancement Mode, High Speed Switch |
2N7002 | NTE491SM | MOSFET, N−Ch, Enhancement Mode, High Speed Switch (SMD) |
2SA499 | NTE159 | NPN Silicon Transistor, Audio Amplifier, Switch |
2SA733 | NTE290A | PNP Silicon Complementary Transistor, Audio Power Amplifier |
2SA970 | NTE290A | PNP Silicon Complementary Transistor, Audio Power Amplifier |
2SA1015 | NTE290A | PNP Silicon Complementary Transistor, Audio Power Amplifier |
2SA1084 | ----- | PNP Silicon Epitaxial, Low-Noise |
2SA1515 | NTE159 | NPN Silicon Transistor, Audio Amplifier, Switch |
2SB54 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch, 40V 200mA |
2SC372(Y) | NTE289 | NPN Silicon Complementary Transistor, Audio Power Amplifier and Switch |
2SC373 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
2SC458 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
2SC828 | NTE199 | NPN Silicon Transistor, High Gain Amplifier |
2SC930(E) | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
2SC945 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
2SC1061 | NTE152 | NPN Silicon Complementary Transistor, Audio Power Amplifier and Switch |
2SC1173 | NTE152 | NPN Silicon Complementary Transistor, Power Amplifier, Switch 90V 3A |
2SC1173(C) | NTE235 | NPN Silicon Transistor, Final RF Power Output |
2SC1518 | NTE293 | NPN Silicon Complementary Transistor, Audio Amplifier and Driver |
2SC1815 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
2SC1843(E,F,P) | NTE199 | NPN Silicon Transistor, High Gain Amplifier |
2SC1906 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
2SC1944 | NTE236 | NPN RF Power Amp, at: 11Meters (27Mhz), 25V 16W, TO-220AB |
2SC1969 | NTE236 | NPN RF Power Amp, at: 11Meters (27Mhz), 25V 16W, TO-220AB |
2SC1971 | NTE342 | NPN Silicon Transistor, RF Power Output, 15V, 7W 175Mhz (works on FM Band as well!) |
2SC2001 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
2SC2078(B,C,D,E) | NTE235 | NPN Silicon Transistor, Final RF Power Output, 4w 150Mhz |
2SC2290 | ----- | NPN Silicon Epitaxial Planar Transistor, covers: 2~30Mhz 60W PEP Power Amp |
2SC2314(D,E) | NTE295 | NPN RF Power Transistor, 2W~5W 12V 1A |
2SC2498 | NTE23 | NPN Silicon Transistor, Ultra High Frequency Amp |
2SC2570 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
2SC2879 | NTE470 | NPN RF Power Output Transistor, 2~30Mhz, 100W PEP, 12V 20A |
2SC3279 | NTE11 | NPN Silicon Complementary Transistor, High Current Amplifier |
2SC3358 | ----- | Bipolar NPN UHF/Microwave- Up to 700GHz! |
2SC5200 | NTE2328 | NPN Silicon Complementary Transistor, Audio Power Output, 200V 15A |
2SC9014 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
2SC9018 | ----- | AM/FM IF Amplifier, Local Oscillator of FM/VHF Tuner |
2SD180 | NTE87 | Silicon Complementary Transistors, High Power Audio |
2SJ471 | ----- | Silicon P-Channel DV–L MOSFET, High Speed Power Switching |
2SJ607 | ----- | P-Channel Power MOSFET, 60V 83A |
2SK37(H) | NTE132 | Silicon N-Channel J-FET, VHF Amplifier, Mixer |
2SK104 | NTE312 | N-Channel Silicon Junction, FET |
2SK19(GR) | NTE133 | N-Channel J-FET, General AF Amplifier |
2SK117 | NTE458 | N-Channel Silicon J-FET, General Purpose, Low Noise, Audio Freq. Amp. |
2SK2231 | ----- | DUAL FET N-Chan, MOSFET, Chopper Regulator, DC-DC Converter |
2SK2956 | NTE2953 | MOSFET, N-Channel, Enhancement Mode, High Speed Switch |
2SK3296 | ----- | MOSFET, Switching N-Channel, Power MOSFET, Industrial Use |
2SK3812 | ----- | Switching N-Channel Power MOSFET, 60V 110A |
3SK74(M) | NTE455 | MOSFET N-Channel Silicon, Dual-Gate MOS, Field Effect Transistor - MOSFET |
3SK81 | NTE455 | MOSFET N-Channel Silicon, Dual-Gate MOS, Field Effect Transistor |
4136 | NTE997 | Quad Op Amp. |
4226 | NTE5260A | Zener Diode 18.0v 50W |
40106(B,BE) | NTE40106B | CMOS Hex Schmitt Triggers (cross to 74HC14) |
40193 | NTE40193B | CMOS Presetable, Up/Down Counters, (Dual Clock with Reset) |
40234 | NTE161 | NPN Silicon Transistor, VHF-UHF Amplifier, Mixer/Osc. |
40403 | NTE100 | PNP Germanium Complementary Transistor, Osc., Mixer, AM Radio, Med. Speed Switch |
40404 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch, 40V 200mA |
40405 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch, 40V 200mA |
40406 | NTE129 | PNP Silicon Complementary Transistor, Audio Output, Video, Driver |
40407 | NTE128 | NPN Silicon Complementary Transistor, Audio Output, Video, Driver |
40408 | NTE16005 | NPN Silicon Complementary Transistor, High Current, General Purpose |
40409 | NTE128 | NPN Silicon Complementary Transistor, Audio Output, Video, Driver |
40410 | NTE129 | PNP Silicon Complementary Transistor, Audio Output, Video, Driver |
40411 | NTE181 | NPN Silicon Power Transistor, High Power Audio Amp. |
40412 | NTE396 | NPN Silicon Transistor, Power Amp., High Speed Switch |
40413 | NTE108 | NPN Silicon Transistor, High Frequency Amplifier |
40414 | NTE108 | NPN Silicon Transistor, High Frequency Amplifier |
40416 | ||
40395 | NTE102A | PNP Germanium Complementary Transistor, Medium Power Amp. |
40396 | NTE103 | NPN Germanium Complementary Transistor, Power Output, Driver |
40396N | NTE103A | NPN Germanium Complementary Transistor, Medium Power Amp. |
40396P | NTE102A | PNP Germanium Complementary Transistor, Medium Power Amp. |
40672 | NTE5697 | TRAIC 600V 40A |
40673 | NTE222 | Field Effect Transistor,(FET) Dual-Gate N–Channel MOSFET 25V 50mA |
40822 | NTE222 | Field Effect Transistor,(FET) Dual-Gate N–Channel MOSFET 25V 50mA |
40EPF06 | ----- | 600V Fast Recovery Diode, 60nS 10A |
4558 | NTE778A | Dual Op. Amp. (use LM4558 instead) |
4N25 | NTE3040 | Optoisolator, NPN Transistor Output, 30v 100mA |
4N26 | NTE3040 | Optoisolator, NPN Transistor Output, 30v 100mA |
4N27 | NTE3040 | Optoisolator, NPN Transistor Output, 30v 100mA |
4N28 | NTE3040 | Optoisolator, NPN Transistor Output, 30v 100mA |
4N29 | NTE3084 | Optoisolator, NPN Photo Darlington Output |
4N32 | NTE3083 | Optoisolator, NPN Photo Darlington Output |
4N33 | NTE3083 | Optoisolator, NPN Photo Darlington Output |
4N35 | NTE3041 | Optoisolator, NPN Transistor Output, 30v 150mA |
4N37 | NTE3041 | Optoisolator, NPN Transistor Output, 30v 150mA |
4N38 | NTE3088 | Optoisolator, NPN Silicon High Voltage - Photo-transistor Output |
5532 | NTE5036A | Zener Diode, 33V 1/2W |
6N135 | NTE3092 | Optocoupler, Hi-Speed, Photo-detector Transistor |
6N136 | NTE3092 | Optocoupler, Hi-Speed, Photo-detector Transistor |
6N137 | NTE3087 | Optocoupler, High CMR, High-speed Logic Gate Output |
6N138 | NTE3093 | Optocoupler, NPN Hi-Speed, Split Darlington Output |
6N139 | NTE3093 | Optocoupler, NPN Hi-Speed, Split Darlington Output |
723C | NTE923D | Precision Voltage Regulator, 40v Max Input, 2v to 37v, 150mA Output (or LM723) |
741 | NTE941M | Single Op Amp. (see LM741CN) |
747 | ----- | Quad Op Amp.(see LM747CN) |
748CV | NTE975 | Op Amp. |
7400 | NTE7400 | QUAD 2-Input NAND Gate |
7402 | NTE7402 | QUAD 2-Input NOR Gate |
7404 | NTE7404 | Hex Inverter |
7407 | NTE7407 | Hex Buffer/Driver |
7408 | NTE7408 | QUAD 2-Input AND Gate |
7410 | ----- | Triple 3-Input NAND Gate |
7411 | NTE7411 | Triple 3-Input AND Gate |
7412 | ----- | Triple 3-Input Positive NAND-Gates with Collector Outputs |
7413 | NTE7413 | Dual NAND Trigger |
7414 | NTE7414 | HEX SCHMIDT-TRIGGER INVERTERS |
7420 | NTE7420 | DUAL 4-Input NAND Gate |
7423 | NTE7423 | Expandable Dual 4-Input NOR Gate |
7430(N) | NTE7430 | 8-Input NAND Gate |
7432 | NTE7432 | QUAD 2-Input OR Gate |
7442 | NTE7442 | BCD to Decimal Decoder |
7445 | NTE7445 | BCD to Decimal Decoders/Drivers |
7447 | NTE7447 | BCD to 7-Segment Decoder/Driver |
7451 | NTE7451 | 2-wide 2-input, 2-wide 3-input AND-OR-INVERT Gates |
7473 | NTE7473 | Dual J-K Flip-Flop, with Clear and Complementary Outputs |
7474 | NTE7474 | Dual D Positive Edge Triggered Flip-Flop with Preset and Clear |
7475 | NTE7475 | 4-Bit Bistable Latches |
7476 | ----- | Dual Master/Slave J-K Flip-Flop |
7480 | NTE7480 | Gated Full Adder |
7483 | NTE7483 | 4-BIT BINARY FULL ADDER |
7485 | NTE7485 | 4-Bit Magnitude Comparators |
7486 | NTE7486 | Quad 2-input XOR Gate |
7489 | NTE7489 | 64-bit Random Access Read/Write Memory |
7490 | ----- | Decade Counter (separate Divide-by-2 and Divide-by-5 sections) |
7491 | NTE7491 | 8-Bit Shift Registers |
7492 | NTE7492 | DECADE/ DIVIDE-BY-TWELVE AND BINARY COUNTERS |
7493 | NTE7493A | 4-Bit Binary Counter |
7495 | NTE7495 | Bidirectional Shift Register |
7497 | NTE7497 | Synchronous 6-bit binary rate multiplier |
74107 | NTE74107 | Dual J-K Flip-Flop with Clear |
74113 | ----- | Dual Negative-Edge-Triggered J-K Flip-Flop with Preset and Complementary Outputs |
74121 | NTE74121 | Monostable Multivibrators, One-Shot with Clear and Complementary Outputs |
74123 | NTE74123 | Dual-Retriggable Monostable Multivibrators, One-Shot with Clear and Complementary Outputs |
74125 | NTE74125 | Quad 3-STATE Buffer |
74133 | ----- | 13-Input NAND Gate |
74138 | NTE74LS138 | 3 to 8-line Decoder/De-multiplexer |
74139 | ----- | Dual 2 to 4-line Decoder/De-multiplexer |
74193(N) | NTE74193 | CMOS Presetable synchronous Binary up/down counter, Dual Clock |
74141 | NTE74141 | TTL - BCD-to-Decimal Decoder/Driver (Used to Drive NIXIE Tubes) |
74150 | NTE74150 | 16-Input Data Selectors/Multiplexers |
74151 | NTE74151 | 8-Line to 1-Line Data Selector/Multiplexer |
74154 | NTE74154 | 4-Line to 16-Line Decoder/De-multiplexer |
74163 | NTE74163 | Synchronous 4-bit Binary Counter with Synchronous Clear |
74164 | NTE74164 | 8-bit Parallel-Out Serial Shift Register with Asynchronous Clear |
74165 | ----- | Parallel-Load 8-Bit Shift Register |
74181 | NTE74181 | 4-bit Arithmetic Logic Unit and Function Generator |
74193 | NTE74193 | Synchronous Up/Down Binary Counter |
74195 | NTE74195 | 4-bit Parallel-Access Shift Register |
74240 | ----- | Octal Buffer with Inverted Three-State Outputs |
74241 | ----- | Octal Buffer with Non-inverted Three-State Outputs |
74244 | ----- | Octal Buffer with Non-inverted Three-State Outputs |
74245 | ----- | Octal Bus Transceiver with Non-inverted Three-State Outputs |
74283 | ----- | 4-bit Binary Full Adder |
74367 | NTE74367 | Hex Bus Drivers with 3-State Outputs |
74574 | ----- | Octal D-Type Edge-Triggered Flip-Flop with Three-State Outputs |
74C14 | NTE74C14 | CMOS Hex Schmitt Trigger |
74C925 | ----- | CMOS 4-Digit Counters w/ Multiplexed 7-Segment Output Drivers |
74HC00 | NTE74HC00 | CMOS Quad 2-input NAND gate |
74HC02 | ----- | CMOS Quad 2-input NOR gate |
74HC04 | NTE74HC04 | CMOS 6-Hex inverters |
74HC14 | NTE74HC14 | CMOS Hex Inverting Schmitt Trigger (cross to 40106) |
74HC20 | ----- | CMOS Dual 4-input NAND gate |
74HC73 | ----- | CMOS Dual JK flip-flop with reset negative-edge Trigger |
74HC74 | NTE74HC74 | CMOS Dual D-type Flip-Flop |
74HC132(N) | NTE74HC132 | CMOS Quad Dual-Input Schimtt NAND Gate |
74HC138 | NTE74HC138 | CMOS 3-to-8 line decoder/De-multiplexer; Inverting |
74HC151N | NTE74HC151 | CMOS 8-input multiplexer |
74HC153 | NTE74HC153 | CMOS Dual 4-input multiplexer |
74HC154 | NTE74HC154 | CMOS 4-to-16 line decoder-multiplexer |
74HC160 | ----- | CMOS Presetable synchronous BCD decade counter, asynchronous reset |
74HC161 | NTE74HC161 | CMOS Presetable synchronous 4-bit binary counter, asynchronous reset |
74HC164(N) | NTE74HC164 | CMOS 8-Bit Serial-Input/Parallel-Output Shift Register |
74HC165 | NTE74HC165 | CMOS 8-bit parallel-in/serial-out shift register |
74HC174 | NTE74HC174 | CMOS Hex D-type flip-flop with reset; positive-edge trigger |
74HC175 | NTE74HC175 | CMOS Quad D-type flip-flop with reset; positive-edge trigger |
74HC192 | ----- | CMOS Presetable synchronous BCD decade, up/down counter |
74HC193 | ----- | CMOS Presetable synchronous Binary counter, Dual Clock |
74HC237 | ----- | CMOS 3-to-8 Line Decoder/De-multiplexer w/Address Latches |
74HC244 | NTE74HC244 | CMOS Logic Non-Inverting Octal Buffers / Line Drivers, w/ 3-State Outputs |
74HC266 | ----- | CMOS Quad Exclusive NOR Gate w/ Open Drain |
74HC373(N) | NTE74HC373 | CMOS Octal D-type Transparent Latch, 3-State |
74HC374(N) | NTE74HC374 | CMOS Octal D-type flip-flop positive-edge trigger 3-state |
74HC390(N) | NTE74HC390 | CMOS Dual-Decade Ripple Counter |
74HC393(N) | NTE74HC393 | CMOS Dual 4-Bit Binary Ripple Counter |
74HC4020(N) | NTE74HC4020 | CMOS 14-Stage Binary Ripple Counter |
74HC4040 | NTE74HC4040 | CMOS 12-Stage Binary Ripple Counter |
74HC4046 | ----- | CMOS Phase Lock Loop |
74HC4052 | ----- | CMOS Dual 4-Channel Analog Multiplexer, De-multiplexer |
74HC573 | NTE74HC573 | CMOS Octal D-type transparent latch, 3-state |
74HC595 | ----- | CMOS 8-Bit Serial-Input/Serial or Parallel-Output Shift Register |
74LS07 | NTE74LS07 | Hex Buffers/Drivers (W/ Open Collector High-Voltage Outputs) |
74LS13 | NTE74LS13 | Dual 4-Input Schmitt Trigger |
74LS21 | NTE74LS21 | DUAL 4-INPUT POSITIVE-AND GATES |
74LS76(A) | NTE74LS76A | Dual JK, Flip-Flop |
74LS86 | NTE74LS86 | Quad 2-Input XOR Gate |
74LS47(N) | NTE74LS47 | BCD to 7-Segment Decoder/Driver w/ Open Collector Outputs |
74LS107 | NTE74LS107 | Dual-JK Negative Edge-Triggered Flip-Flop |
74LS138 | NTE74LS138 | Decoder / De-multiplexer |
74LS148(N) | NTE74LS148 | 8-Line to 3-Line, Priority Encoder (SN74LS148N will also work) |
74LS154 | ----- | 4-Line to 16-Line Decoder/De-multiplexer |
74LS156(N) | NTE74LS156 | Dual 2-Line to 4-Line, Decoders / De-multiplexer, w/ Open-Collector Outputs |
74LS164(N) | NTE74LS164 | 8-Bit Serial In/Parallel Out Shift Register |
74LS181(N) | NTE74LS181 | 4-Bit Arithmetic Logic Unit |
74LS221(B) | NTE74LS221 | Dual Non-Retriggerable One-Shot with Clear and Complimentary Outputs |
74LS245(N) | NTE74LS245 | 3-State Octal Bus Transceiver |
74LS247 | NTE74LS247 | BCD to 7-Segment Decoder/Driver |
74LS573 | ----- | CMOS Octal D-type transparent latch, 3-state (use the 74HC573) |
74LS367 | NTE74LS367 | Hex Tri-State Buffers |
74LS595N | ----- | 8-Bit Shift Registers With Output Latches |
74S133N | NTE74S133 | 13-Input NAND Gate |
7555 | NTE955M | CMOS, Timer, Oscillator, (Lower current draw then the NE555) |
7805 | NTE960 | 3-Terminal Positive Voltage Regulator, 5V 1A |
7809 | NTE1910 | 3-Terminal Positive Voltage Regulator, 9V 1A |
7812 | NTE966 | 3-Terminal Positive Voltage Regulator, 12V 1A |
7815 | NTE968 | 3-Terminal Positive Voltage Regulator, 15V 1A |
78L05 | NTE977 | Positive 3 Terminal Voltage Regulator, 5V 100mA |
78L08 | NTE981 | Positive 3 Terminal Voltage Regulator, 8V 100mA |
78L09 | NTE1902 | Positive 3 Terminal Voltage Regulator, 9V 100mA |
78L12 | NTE950 | Positive 3 Terminal Voltage Regulator, 12V 100mA |
78L15 | NTE951 | Positive 3 Terminal Voltage Regulator, 15V 100mA |
78L33 | ----- | Positive 3 Terminal Voltage Regulator, 3.3V 100mA |
78L82(AC) | NTE981 | Positive 3 Terminal Voltage Regulator, 8V 100mA |
7905 | NTE961 | Voltage Regulator, Negative, 5V, 1A |
7912 | NTE967 | Voltage Regulator, Negative, 12V, 1A |
7915 | NTE969 | Voltage Regulator, Negative, 15V, 1A |
79L05 | NTE1917 | Negative 3 Terminal Voltage Regulator, -5V 100mA |
79L08 | NTE1979 | Negative 3 Terminal Voltage Regulator, -8V 100mA |
79L09 | ----- | Negative 3 Terminal Voltage Regulator, -9V 100mA |
79L12 | NTE1904 | Negative 3 Terminal Voltage Regulator, -12V 100mA |
79L15 | NTE1905 | Negative 3 Terminal Voltage Regulator, -15V 100mA |
AA119 | NTE109 | Germanium Diode, Fast Switching General Purpose (use 1N34) |
AA121 | NTE109 | Germanium Diode, Fast Switching General Purpose (use 1N34) |
AC-128 | NTE158 | PNP Germanium Audio Power Amplifier |
AC187 | NTE103A | Germanium Complementary, Medium Power Amp. (use this if a 2N2222 is too Noisy) |
8550C | NTE290A | Silicon Complementary Transistor, 100V 500mA |
AD557JN | ----- | DACPORT, Low-Cost Complete, uP-Compatable 8-Bit DAC |
AD587 | ----- | High Precision 10V Reference |
AD623AN | ----- | Single-Supply, Rail-to-Rail, Instrumentation Amplifier |
AD722 | ----- | RGB to NTSC/PAL Encoder, 16-Pin DIP |
AD724 | ----- | RGB to NTSC/PAL Encoder, 16-Pin SOIC |
AD797 | ----- | Ultra-Low Distortion, Ultra-Low Noise, Op-Amp... |
(If you don't care about noise, use an NE5532N/NE5534N) | ||
AD820 | ----- | Single Supply, Rail-To-Rail, Low Power FET-Input Op Amp. |
AD8307(AN) | ----- | DC-500Mhz, 92dB, Logarithmic Amplifier / Detector |
AD8318 | ----- | Logarithmic Detector/Controller - 1 MHz to 8 GHz, 70 dB |
AD8530 | ----- | Dual Op-Amp |
AD9850 | ----- | CMOS, 125 MHz Complete DDS Synthesizer |
ADC0804 | NTE2053 | 8-Bit MPU, Compatible A/D Converter |
ADC0820 | ----- | 8-Bit High Speed mP Compatible A/D Converter with Track/Hold Function |
ADC0831 | ----- | 8-Bit Serial I/O A/D Converter with Multiplexer Option |
ADM232 | NTE7142 | 5V-Powered, Multichannel RS-232 Driver/Receiver |
AN6884 | NTE1561 | 5-LED VU Level Meter, 18V 12mA (9-Lead SIP package) |
A5T3644 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
AY-3-8910 | ----- | Sound Generator |
BA121 | NTE611 | Varactor Diode |
BA482 | NTE555A | Silicon PIN Diode, VHF Band Switch |
BAS16 | NTE593 | Silicon Diode, High Speed Switch, 75V 800mA |
BAT42 | ----- | Small Signal Schottky Diode, 10mA or 50mA |
BAT43 | ----- | Small Signal Schottky Diode, 2mA or 15mA |
BAT45 | ----- | Small Signal Schottky Diode, 30mA or 60mA |
BAT46 | ----- | Small Signal Schottky Diode, 150mA |
BAT49 | ----- | Small Signal Schottky Diode, 500mA |
BAT54 | NTE637 | Schottky Barrier Diode, Surface Mount |
BAT54C | ----- | Schottky Barrier 2-Diodes, Surface Mount |
BAT85 | NTE585 | Silicon Rectifier Diode, Schottky Barrier, Fast Switching |
BAV99 | NTE632 | Silicon Rectifier Diode, Dual-Switching Series Pair, low-C |
BAW62 | NTE519 | Silicon Rectifier Diode, Ultra Fast Switch |
BA1404 | NTE7200 | FM Stereo Transmitter |
BA4560(F) | NTE928M | Low Power Dual Op. Amp. |
BA5406 | NTEOBS-NLA | Stereo Power Amplifier, 5W-5W, 12v 40mA |
BA5417 | NTE7207 | Stereo Power Amplifier, 5W-5W, 15v 45mA |
BB102 | ----- | Varactor Diode |
BB109G | NTE614 | Voltage Variable Capacitance Diode, (Tuning Diode) 33pF |
BB119 | ----- | Variable Capacitance Diode 17pF |
BB405 | ----- | UHF Varicap Diode, 30V 20mA |
BB809 | ----- | VHF Varicap Diode, 30V 20mA |
BC107 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
BC108 | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
BC108C | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
BC109(C) | NTE123A | NPN Silicon Complementary Transistor, General Purpose |
BC140 | NTE128 | NPN Silicon Complementary Transistor, Audio Output, Video, Driver 140v |
BC148(A,B,C) | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC157((A,B) | NTE159 | NPN Silicon Transistor, Audio Amplifier, Switch |
BC160 | NTE129 | PNP Silicon Complementary Transistor, Audio Output, Video, Driver 80v |
BC171A | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC177 | NTE234 | PNP Silicon Transistor, Low Noise, High Gain Amplifier |
BC183 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC184L(LB,LC) | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC212 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC213(L) | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC214L(LA,LB,LC) | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC237 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC238C | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
BC239 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC239C | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
BC307 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC327 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC328 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC337 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC338 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC478 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC489B | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC546B | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC547(B) | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC547C | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
BC548 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC549 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC549C | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
BC550(B) | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BC550C | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
BC556 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC557 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC558 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC559(A,B) | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch |
BC585 | NTE2409 | PNP Silicon Transistor, General Purpose, Surface Mount |
BC639 | NTE382 | NPN Silicon Complementary Transistor, Audio Frequency Driver |
BC640 | NTE383 | PNP Silicon Complementary Transistor, Audio Frequency Driver |
BC817 | NTE2406 | NPN General Purpose Amp., Surface Mount |
BC848 | NTE2408 | NPN Silicon Transistor, Surface Mount SOT-23 |
BC850 | NTE2408 | NPN Silicon Transistor, General Purpose, Surface Mount |
BC858 | NTE2409 | PNP Silicon Transistor, General Purpose, Surface Mount |
BCF32 | NTE2408 | NPN Silicon Transistor, Surface Mount SOT-23 |
BCX38A | NTE2341 | NPN Silicon Complementary Transistor, Darlington Driver, 800mW - TO92 |
BCX70H | NTE2408 | NPN Silicon Transistor, Surface Mount SOT-23 |
BCY31 | NTE129 | PNP Silicon Complementary Transistor, Audio Output, Video, Driver |
BD131 | NTE184 | NPN Silicon Complementary Transistor, Audio Power Amplifier, Switch |
BD132 | NTE242 | PNP Silicon Complementary Transistor, Audio Power Amplifier, Switch |
BD135 | NTE375 | NPN Silicon Transistor, TV Vertical Output |
BD136 | NTE374 | PNP Silicon Complementary Transistor, Audio Amplifier, Driver |
BD139 | NTE375 | NPN Silicon Transistor, TV Vertical Output |
BD140 | NTE374 | PNP Silicon Complementary Transistor, Audio Amplifier, Driver |
BD242(A) | NTE153 | PNP Silicon Complementary Transistor, Audio Power Amplifier, Switch |
BD244C | NTE332 | PNP Silicon Complementary Transistor, Audio Power Amplifier, Switch |
BD267(A) | NTE263 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
BD437 | NTE184 | NPN Silicon Complementary Transistor, Audio Power Amplifier, Switch |
BD438 | NTE185 | PNP Silicon Complementary Transistor, Audio Power Amplifier, Switch |
BD649 | NTE263 | NPN Silicon Complementary Transistor, Darlington Power Amplifier, TO220 |
BD650 | NTE264 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
BD676(A) | NTE254 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
BD677(A) | NTE253 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
BD679A | NTE253 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
BD681 | ----- | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
BD682 | NTE254 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
BDX53A | NTE263 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
BDX53C | NTE2343 | NPN Silicon Complementary Transistor, Darlington Power Amplifier, Switch |
BDX54A | NTE264 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
BDX54C | NTE264 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
BDX87(A,B,C) | NTE247 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
BF115 | NTE123AP | Silicon NPN Transistor, Audio Amplifier, Switch |
BF184 | NTE161 | NPN Silicon Transistor, VHF-UHF Amplifier, Mixer/Osc |
BF196 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
BF199 | NTE229 | NPN Silicon Transistor, VHF Oscillator, Mixer, IF Amp |
BF240 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner, also Test Equipment |
BF245(A,B,C) | NTE133 | General Purpose N-Channel JFET (use a 2N3819 instead) |
BF256 | NTE132 | Silicon N-Cannel JFET, VHF Amplifier, Mixer |
BF256C | NTE133 | General Purpose N-Channel JFET (use a 2N3819 instead) |
BF450 | NTE159 | PNP Silicon Complementary Transistor, Audio Amplifier, Switch |
BF469 | NTE157 | NPN Silicon Transistor, Audio Power Amp, High Voltage Converter |
BF470 | NTE39 | NPN Silicon Transistor, Line-Operator Series Pass/Switching Regulator |
BF494(B) | NTE229 | NPN Silicon Transistor, VHF Oscillator, Mixer, IF Amp |
BF960 | NTE455 | MOSFET N-Channel Silicon, Dual-Gate MOS, Field Effect Transistor |
BF981 | ----- | Silicon N-Channel Dual-Gate MOSFET |
BFR90 | NTE65 | NPN Silicon Transistor, High Voltage, Low Noise for CATV, MATV |
BFR92(A) | NTE2404 | NPN Silicon Complementary Transistor, Low Noise, UHF/VHF Amplifier |
BFY90 | NTE316 | NPN Silicon Transistor, High Gain, Low Noise |
BP104 | ----- | Silicon PIN Photodiode |
BPW40 | ----- | Silicon NPN Epitaxial Planar Phototransistor |
BPX25A | NTE3036 | NPN Phototransistor, Silicon Photo Darlington Light Detector |
BPX43 | NTE3032 | NPN Phototransistor Detector, NPN–Si, Visible & IR |
BR100 | NTE6408 | DIACS 30v |
BR1005 | NTE53000 | Single Phase Bridge Rectifier 200v 10A |
BR81D | NTE166 | 100v 2A Bridge Rectifier Rectangular |
BR103 | NTE5400 | SCR 30v 0.8A |
BR354 | NTE5342 | Silicon Bridge Rectifier, Single-Phase, 600V 40A |
BRX49 | NTE5405 | Silicon Controlled Rectifier (SCR), 400v 0.8 Amp Sensitive Gate, TO92 |
BRY35 | ----- | Programmable unijunction transistor/ Silicon controlled switch |
BS107 | NTE492 | MOSFET N-Channel, Enhancement-Mode, High-Speed Switch |
BS170 | NTE490 | MOSFET Transistor, Enhancement-Mode |
BSN20 | ----- | MOSFET N-Channel, Enhancement Mode, Field Effect |
BSS123 | ----- | N-Channel Logic Level Enhancement Mode Field Effect |
BSY18 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
BT136 | ----- | TRIAC, Sensitive Gate |
BT137-800 | NTE5609 | TRIAC, 600v 8A |
BT137X | ----- | Triac's (use the above device) |
BT151 | NTE5466 | SCR 600V 10A |
BT169D | ----- | Thyristor Logic Level, SCR, 200V 0.5A |
BTA08-600C | NTE56059 | TRIAC, 600v 16A, Isolated TAB |
BTA10-600B | NTE5645 | TRIAC, 600v 10A, Isolated TAB |
BTA41-600(A,B) | NTE56031 | TRIAC, 600V 40A, Isolated TAB |
BTA41-400(A) | NTE56030 | TRIAC, 400V 40A, Isolated TAB |
BT136-(800G) | NTE5610 | TRIAC, 400v 8A |
BU406 | NTE379 | NPN High Voltage Switch, up to: 700V 12A |
BUF634 | ----- | High-Speed Buffer 250mA, 2.25V~18V |
BU211 | NTE283 | NPN Silicon Transistor, Horizontal Output, Switch |
BUT56(A) | NTE2333 | NPN Silicon Transistor, Switching Power Applications |
BUZ11(A) | NTE2389 | MOSFET N-Channel, Enhancement Mode, High Speed Switch |
BUZ71 | NTE66 | MOSFET N–Channel, Enhancement Mode, High Speed Switch |
BUZ74(A) | NTE2380 | MOSFET N–Channel, Enhancement Mode, High Speed Switch |
BUZ350 | NTE2376 | MOSFET N–Channel, Enhancement Mode, High Speed Switch |
BUZ900 | NTE2906 | MOSFET N-Channel, Enhancement Mode, High Speed Switch |
BUZ905 | NTE2998 | MOSFET P-Channel, Enhancement Mode, High Speed Switch |
BY229-200 | NTE581 | General purpose Silicon Rectifier, Fast Recovery Diode, 400v 8A |
BZX55C2V7 | NTE5002A | ZENER Diode 2.7v 0.5W |
BZX79C10 | NTE5019A | ZENER Diode 10.0v 0.5W |
BZX79C12 | NTE5012A | ZENER Diode 12.0v 0.5W |
BZX79C24(V) | NTE5031A | ZENER Diode 24.0v 0.5W |
BZX85C5V1 | NTE135A | ZENER Diode 5.1v 1W |
BZX84C6V2 | NTE5013SM | ZENER Diode 6.2v 300mW 250mA SOT-23 (Direct replacement for the BZX84) |
BZY18 | NTE142A | ZENER Diode 12.0v 1W |
BZY88 | NTE5021A | ZENER Diode 12.0v 0.5W |
C106B(1,2) | NTE5455 | TRIAC 200V 4A |
C106D | NTE5457 | TRIAC 400v 4A (for higher Current Output, use: S2003LS1) |
C106E | NTE5458 | TRAIC 600V 4A |
C106Y | NTE5455 | TRIAC 200v 4A |
C945 | NTE85 | NPN Silicon Transistor, General Purpose Amplifier |
C3870 | NTE2337 | NPN Silicon Transistor, High Speed Switch |
C9012 | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch (comp. NTE123AP) |
C9013 | NTE128P | NPN Silicon Complimentary, General Purpose Amp. |
CA3046(E) | NTE912 | General Purpose Transistor Array, 3 Isolated, 1 Differentially-Connected |
CA3080(A) | NTE902 | Operational Transconductance Amplifier 36v |
CA3080E | NTE996 | Operational Transconductance Amplifier 18v |
CA3086(E) | NTE912 | NPN General Purpose Transistor Array |
CA3100 | NTE871 | Windeband High Speed Op. AMP. |
CA3130(E) | NTE7144 | PMOS Operational Amplifier, w/MOSFET Input, Bipolar Output |
CA3140(E) | NTE7144 | PMOS Operational Amplifier, w/MOSFET Input, Bipolar Output |
CA3161 | ----- | BCD to Seven Segment, Decoder/Driver |
CA3162 | ----- | A/D Converters for 3-Digit Displays |
CA3189E | NTE7016 | FM IF System |
CA3237(E) | NTE1682 | Pre-Amp Circuit for Remote Control Signal Receivers |
CA3240(E) | NTE7141 | Dual BIMOS Operational Amplifier, w/MOSFET Input, Bipolar Output (use LM1458 instead) |
CD4001 | NTE4001B | CMOS Quad 2-Input, NOR Buffered B Gate |
CD4002 | NTE4002B | CMOS Dual 4-Input NOR Gate |
CD4004 | ----- | CMOS Binary Up Counter |
CD4006 | NTE4006B | CMOS 18-Stage Static Shift Register |
CD4007 | NTE4007 | CMOS Dual Complementary Pair Plus Inverter |
CD4009 | NTE4009 | CMOS Hex Buffers / Converters |
CD4011 | NTE4011B | CMOS Quad 2-Input, NAND Buffered B Gate |
CD4012 | NTE4012B | CMOS Dual 4-Input NAND Gate |
CD4013B | NTE4013B | CMOS Dual D-Type Flip-Flop |
CD4014 | NTE4014B | CMOS 8-Stage Static Shift Register |
CD4016 | NTE4016B | CMOS Quad Bilateral Switch |
CD4017BCN(A,B) | NTE4017B | CMOS Decade Counter/Divider |
CD4019 | NTE4019B | CMOS Quad AND/OR Gate |
CD4020 | NTE4020B | CMOS 14-stage binary counter |
CD4021 | NTE4021B | CMOS 8-Stage Static Shift Register |
CD4022 | NTE4022B | CMOS Divide-by-8 Counter/Divider |
CD4023 | NTE4023B | CMOS Triple 3-Input NAND |
CD4024 | NTE4024B | CMOS 7-Stage Binary Counter |
CD4025 | NTE4025B | CMOS Triple 3-Input NOR |
CD4026 | NTE4026B | CMOS BCD Decade Counter / Divider, Display Enable |
CD4027 | NTE4027B | CMOS Dual J-K Flip-Flop |
CD4028 | NTE4028B | CMOS BCD/Decimal Decoder |
CD4029 | NTE4029B | CMOS Preset UP/DOWN Counter |
CD4030 | NTE4030B | CMOS Quad Exclusive OR |
CD4031B | NTE4031B | CMOS 64-Stage Static Shift Register |
CD4033BE | NTE4033E | CMOS Decade Counter / Divider, Ripple-Blanking Input |
CD4035 | NTE4035B | CMOS 4-Stage Parallel in/Parallel Out Shift Register |
CD4040 | NTE4040B | CMOS 12-Stage Binary/Ripple Counter |
CD4042 | NTE4042B | CMOS Quad Clocked "D" Latch |
CD4043 | NTE4043B | CMOS Quad 3-State R/S Latch NOR |
CD4044 | NTE4044B | CMOS Quad 3-State NAND R/S Latch |
CD4046 | NTE4046B | CMOS MICROPOWER PHASE-LOCKED LOOP |
CD4047 | NTE4047B | CMOS Low Power Monostable/Astable Multivibrator |
CD4049 | NTE4049 | CMOS Hex Buffer, Inverting |
CD4050 | NTE4050B | CMOS Hex Buffer, Non-Inverting |
CD4020 | NTE4020B | CMOS 14-Stage Ripple/Carry Binary Counter/Divider, W/ Logic-Level Conversion |
CD4051(B) | NTE4051B | CMOS Single 8-Channel Analog Multiplexer/Demultiplexer W/ Logic-Level Conversion |
CD4053 | NTE4053B | CMOS Single 8-Channel Analog Multiplexer/Demultiplexer, Dual 4-Chan, Triple 2-Chan |
CD4053B | NTE4053B | CMOS Triple 2-Channel Analog Multiplexer/Demultiplexer, ? |
CD4060 | NTE4060B | CMOS 14-Stage Ripple-Carry Binary Counter/Divider And Oscillator |
CD4066 | NTE4066B | CMOS Quad Bilateral Switch |
CD4068B | NTE4068B | CMOS 8-Input NAND/AND Gate |
CD4069 | NTE4069 | CMOS 6-Inverter Circuits |
CD4070(B) | NTE4070B | CMOS Quad 2-Input eXclusive-OR Gate |
CD4071(B) | NTE4071B | CMOS Quad 2-Input OR/AND Buffered B Series Gate |
CD4073(B) | NTE4073B | CMOS Triple 3-Input AND Gate |
CD4081(B) | NTE4081B | CMOS Quad 2-Input AND Gate |
CD4093B | NTE4093B | CMOS Quad 2-Input NAND Schmitt Trigger |
CD4094(B) | NTE4094B | CMOS 8-Bit Shift Register/Latch with 3-State Outputs |
CD4098(B,BC) | NTE4098B | CMOS Dual Monostable Multivibrator |
CD40106(BC) | NTE40106B | CMOS HEX Schmitt Trigger |
CD40193 | NTE40193B | CMOS Presettable, Up/Down Counters, (Dual Clock with Reset) |
CD4511 | NTE4511B | CMOS BCD-to-7 Segment Latch/Decoder/Driver |
CD4512 | NTE4512B | CMOS 8-Channel Buffered Data Selector |
CD4514 | NTE4514B | CMOS 4-Bit Latch 4-to-16 Line Decoder with Output, High on Select |
CD4515 | NTE4515B | CMOS 4-Bit Latch 4-to-16 Line Decoder with Output, Low on Select |
CD4516 | NTE4516B | CMOS Presettable Binary Up-Down Counter |
CD4517B | NTE4517B | CMOS Dual 64-Stage Static Shift Register |
CD4518 | NTE4518B | CMOS Dual BCD Up-Counters |
CD4519 | ----- | CMOS 2-Line Digital Multiplexer - Non-inverted outputs |
CD4520 | NTE4520B | CMOS Dual Binary Up-Counters |
CD4521B | NTE4521B | CMOS 24-Stage Frequency Divider |
CD4522B | NTE4522B | CMOS Programmable BCD Divide-By-N Counter |
CD4526B | NTE4526B | CMOS Programmable Divide by N 4-Bit Binary Counter |
CD4527 | NTE4527B | CMOS BCD Rate Multiplier |
CD4528 | NTE4528B | CMOS Dual Monostable Multivibrator |
CD4529BCN | NTE4529B | CMOS Dual 4-Channel or Single 8-Channel Analog Data Selector |
CD4532B | NTE4532B | CMOS Encoder, Priority, 8-Line to 3-Line Binary Code |
CD4536B | NTE4536B | CMOS Programmable Timer |
CD4541(B) | NTE4541B | CMOS Programmable Timer, High Voltage Type (20V Rating) |
CD4553(BJP) | NTE4553B | CMOS 3-Digit BCD Counter |
CD4555 | NTE4555B | CMOS Dual Binary to 1-of-4 Decoder/Demultiplexer w/ Outputs High on Select (equal to NE556) |
CD4556B | NTE4556B | CMOS Dual Binary 1-of-4 Decoder/Demultiplexer |
CK722 | NTE102 | Germanium Complementary Transistor, Power Output, Driver |
CNY17-1 | NTE3041 | Optoisolator NPN Transistor Output |
CNY17-3 | NTE3041 | Optoisolator NPN Transistor Output |
D45H8 | NTE378 | PNP Silicon Complementary Transistors, Power Amp Driver, Output, Switch |
DB3 | NTE6408 | Bilateral Trigger Diode (DIACS), 32V 2A |
DS1666-10 | ----- | Audio Digital Resistor |
ECG3079 | NTE3079 | Single Digit Numeric Display, Size: 0.56", Seven Segment. Common Cathode |
ECG5400 | NTE5400 | Silicon Controlled Rectifier (SCR), 30v 0.8 Amp Sensitive Gate, TO92 |
ELM446 | ----- | 50Hz Generator |
EQA01-11R | NTE5020A | Zener, 11V 1/2W 5% + |
EQA01-07R | NTE5071A | Zener, 7V 1W 5% + |
FGM-3 | ----- | Fluxgate |
FND500 | NTE3079 | Single Digit Numeric Display 0.56", Seven Segment, RHDP |
FQP30N06 | NTE2389 | N-Channel Enhancement Mode, High Speed Switch, Logic Level MOSFET 60V 30A |
FQP50N06 | NTE2395 | N-Channel Enhancement Mode, High Speed Switch, MOSFET |
FQP50N06L | NTE2986 | N-Channel Enhancement Mode, High Speed Switch, Logic-Level MOSFET |
FR302 | NTE580 | General Purpose Silicon Rectifier, Fast Recovery, 600v 3A |
FR307 | NTE577 | Silicon Diode, General Purpose, Fast Recovery Switch, 1000v 5A |
FR603(G) | NTE589 | Silicon Rectifier, General Purpose, Fast Recovery 400V 6A |
FST3253 | ------ | Dual 4:1 Multiplexer/Demultiplxer Buss Switch |
H11AA2 | NTE3089 | Optoisolator AC Input, Silicon NPN, Phototransistor Output, 6-PIN DIP |
H11L1(M) | NTE3090 | Optoisolator Schmitt Trigger Output |
H11F3 | NTE3085 | Optoisolator Photon Coupled Bilateral Analog FET |
HCF4520(B) | NTE4520B | Dual Up-Counters |
HEP154 | NTE116 | General Purpose Silicon Rectifier 600V 1A, Peak 30A |
HEP230 | NTE104 | Germanium PNP Transistor, Audio Frequency Power Amp. |
HF10-12S | ----- | VHF Power Amplifier, 10w 30Mhz, 10Meters |
HT12D | ----- | 212 Series Decoder |
HT12E | ----- | 212 Series Encoder |
HT-35 | NTE6408 | Bilateral Trigger Diodes (DIACS), 36V 2A |
HUF75337(P3) | ----- | N-Channel UltraFET Power MOSFET, 75A 55V, 0.014Ω TO-220 |
ICL232IPE | ----- | Dual RS-232 Transceiver ( can use MAX232(A,N) ) |
ICL7611 | ----- | Single Operational Micropower Amplifier |
ICL7660 | ----- | Switched-Capacitor Voltage Converter, Negative Output (or MAX1044) |
ICL7662 | ----- | Voltage Inverter, (+12v in, -12v out) (get from MAXIM-IC) |
ICL7665 | ----- | Microprocessor Voltage Monitor w/ Dual Over/Under Voltage Detection |
ICL8038 | NTE864 | Precision Waveform Generator |
ICL8069 | ----- | Low-Voltage Reference 1.2v |
ICL8211 | ----- | Programmable Voltage Detectors |
ICM7555CBA | NTE955SM | CMOS Timer, Oscillator, Lower current version of NE555 - SOIC-8 Surface Mount |
ICM7555(CN) | NTE955MC | CMOS Timer, Oscillator, Lower current version of NE555 - DIP, 2Mhz MAX |
ICM7555M | NTE955M | CMOS Timer, Oscillator, Lower current version of NE555 - DIP |
ICM7555IPA | NTE955MC | CMOS Timer, Oscillator, Lower current version of NE555 - DIP, 1mW-Idle |
ICM7555ISA+ | ----- | CMOS Timer, Oscillator, Lower Current Version of NE555 - DIP or SOT-23 Package |
ICM7555S | NTE955S | CMOS Timer, Oscillator, Lower current version of NE555 - SIP |
ICM7556(IPD) | NTE978 | CMOS Dual Timer, (like an NE556, but lower current draw) |
IF-D93 | ----- | Fiber Optic Receiver |
IF-E96 | ----- | Fiber Optic Transmitter |
INA105 | ----- | Precision Unity Gain - Differential Amplifier |
INA219 | ----- | Zero-Drift, Bidirectional Current, Power/Monitor i2c + |
IR2155 | ----- | MOSFET Self-Oscillating, Half-Bridge Driver |
IRF510 | NTE2382 | MOSFET N-Channel, Enhancement Mode, High Speed Switch, 100V 9.2A |
IRF511 | NTE66 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 100V 14A |
IRF512 | NTE66 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 100V 14A |
IRF513 | NTE66 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 100V 14A |
IRF420 | NTE2386 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 600V 6.2A |
IRF520 | NTE2382 | MOSFET N-Channel, Enhancement Mode, High Speed Switch, 100V 9.2A |
IRF530 | NTE66 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 100V 14A |
IRF540(N) | NTE2396 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 100V 20A |
IRF610 | NTE67 | TMOS N–Channel, Enhancement Mode, High Speed Switch, 400V 18A |
IRF620 | NTE2388 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 200V 18A |
IRF630(M,FP,R) | NTE2388 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 200V 18A |
IRF630A | NTE2374 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 200V 18A |
IRF1404 | NTE2908 | MOSFET N-Channel Enhancement Mode, High Speed Switch, 40V 162A |
IRF1405 | ----- | Single N-Channel HEXFET Power MOSFET, 55V |
IRF4905 | ----- | HEXFET Power-MOSFET 55V |
IRF9Z34 | NTE2371 | MOSFET P-Channel Enhancement Mode, High Speed Switch, 100V 23A |
IRF9540 | NTE2371 | MOSFET P-Channel Enhancement Mode, High Speed Switch, 100V 23A |
IRFP054(N) | NTE2920 | MOSFET N-Channel Enhancement Mode, High Speed Switch, 100V 70A |
IRF9Z34N | ----- | P-Channel - HEXFET Power MOSFET, 55V 19A |
IRFZ44(N) | NTE2395 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 50A |
IRFZ46(N) | NTE2975 | MOSFET N–Channel, Enhancement Mode, High Speed Switch, 28A |
IRL530 | NTE2987 | MOSFET N-Channel Enhancement Mode, High Speed Switch, 15V 20A |
IRLZ14 | NTE2984 | MOSFET, Logic-Level, N–Ch, Enhancement Mode, High Speed Switch, 60V 17A |
IS435 | ----- | Built-in Amp. type Light Detector - Low Level Output |
IS436 | ----- | Built-in Amp. type Light Detector - High Level Output |
ISD1000 | ----- | Voice Recorder/Playback |
ISD1400 | ----- | Voice Recorder/Playback |
J111 | NTE468 | N-Channel Silicon J-FET, Chopper, High-Speed Switch |
J201 | NTE458 | N-Channel Silicon J-FET, General Purpose, Low Noise, Audio Freq. Amp. |
J309(G) | NTE2902 | N-Channel Silicon Junction, Field Effect Transistor |
J310 | NTE2902 | N-Channel Silicon Junction, Field Effect Transistor |
KA2206 | NTE1667 | 2.3 Watts per channel, Power Amplifier, Bridging will give 4.7 Watts |
KA2209 | ----- | Stereo Power Amplifier, 1W |
KA2284 | NTE1561 | 5 LED VU Level Meter - 6-18V, .6A |
KA76L05 | ----- | Voltage Regulator 33V IN MAX, 5V out 4mA |
KBL01 | NTE5318 | Single Phase Bridge Rectifier 200v 4A |
KBP103G | NTE167 | Single Phase Bridge Rectifier, 200v 2A |
KBP201(G) | NTE166 | Single Phase Bridge Rectifier, 100v 2A |
KBPC104 | NTE5314 | Single Phase Bridge Rectifier, 400v 8A |
KBU401(G) | NTE5329 | Single Phase Bridge Rectifier 140v 6A |
KDV149 | NTE618 | Silicon Tuning Diode, for AM / Shortwave Radio |
KSP2222A | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
KV1236 | NTE618 | Silicon Tuning Diode, for AM / Shortwave Radio |
L14F1(F2) | NTE3036 | Phototransistor, Silicon NPN, Photo Darlington, Light Detector |
L200 | NTE5629 | TRIAC 400v 4A |
L200C | NTE1942 | Positive Adjustable Voltage Regulator, 2.85V to 36V, 2A |
L200CV | ----- | Adustable Voltage & Current Regulator |
L272(B) | NTE1854D | Dual Power Op-Amp |
L272M | NTE1854M | Dual Power Op-Amp |
L293 | NTE1749 | Push-Pull 4-Channel Motor Driver, 1A |
L293D | ----- | Push-Pull 4-Channel Driver with Diodes, 800mA (can use SN754410) |
L297 | ----- | Stepper Motor Controller's 5V-10V |
L298(N,K) | NTE7071 | Dual, Full-Bridge Motor Driver, 4A |
L2004F31 | NTE5629 | TRIAC 400V 4A |
L4949 | ----- | Multifunction very Low Drop Voltage Regulator, 5V~28V, 5mV |
L4960 | NTE7107 | Switching Regulator, 2.5A |
LA3160 | NTE1170 | Dual Preamp for small circuits and Car Radios |
LA3161 | NTE1659 | Dual AF Amp for small circuits and Car Radios |
LA4440(AT,R) | NTE1377 | AF Power Amplifier, 6Wx6W or Bridge 19W, 18V 100mA w/ Mute |
LA4555 | ----- | Power Amplifier, Mono, 2.3W into a 4Ω load |
LB1409 | NTE1513 | 9-Step LED Driver Circuit for Logarithmic Scale |
LD1086V33 | ----- | 1.5A Low-Drop Fixed and Adjust Positive, Voltage Regulators |
LF351(N) | NTE857M | Low–Noise, JFET–Input, Operational Amplifier |
LF353(N) | NTE858M | Dual Low-Noise JFET-Input, Op. Amp. |
LF355 | NTE857M | Low–Noise, JFET–Input, Operational Amplifier |
LF355N | NTE937M | J-FET Input Operational Amplifier |
LF356(N,AN) | NTE937M | J-FET Input Operational Amplifier |
LF441CN | NTE887M | Low-Power JFET Op Amp |
LM34 | ----- | Precision Fahrenheit Temp. Sensor, Thermistor |
LM35 | ----- | Precision Centigrade Temp. Sensor, Thermistor |
LM133 | ----- | Negitive Voltage Regulator, 3-Terminal, 1.2V~33V, 3A |
LM150(K) | NTE970 | Positive Voltage Regulator, 3-Terminal, 1.2V~33V, 3A |
LM293D | ----- | LOW POWER DUAL BIPOLAR COMPARATORS (Use LM393D or NTE943M) |
LM301(AH,H) | NTE1171 | Operational Amplifier |
LM301AN | NTE975 | Operational Amplifier |
LM308N | NTE938M | Precision Operational Amplifier |
LM309K | NTE309K | Voltage Regulator, 5.05v 1A TO-3 |
LM311 | NTE922 | VOLTAGE COMPARATOR |
LM317(T) | NTE956 | 3–Terminal Adjustable Positive, Voltage Regulator, 1.2v to 37v 1.5A |
LM317L(LZ) | NTE1900 | 3–Terminal Adjustable Positive, Voltage Regulator, down to 1.2v 100mA |
LM318(N,P) | NTE918M | High Speed Op. Amp. |
LM319N | NTE919D | High Speed Dual Comparator |
LM324(AN) | NTE987 | QUAD OP-AMP |
LM334Z | ----- | Adjustable Current Sources, 3-Terminal, TO-92 1v-40v |
LM335Z | NTE7225 | Precision Temperature Sensor, Centigrade TO-92 |
LM336-Z2.5 | NTE952 | Precision 2.5V Shunt |
LM337(T) | NTE957 | 3–Terminal Adjustable Negative, Voltage Regulator, -1.2v to -37v 1.5A |
LM337LZ | NTE1901 | Negative Adjustable, Voltage Regulator, -1.2 to -37V, 100mA TO-92 |
LM338(K) | NTE935 | 3–Terminal Adjustable Positive Voltage Regulator, 1.2V to 32V, 5A |
LM339(AD,AN,N) | NTE834 | Low Power Low Offset, Voltage Comparator |
LM340-5 | NTE309K | 3–Terminal Positive Voltage Regulator, 5V 1.0A TO-3 |
LM340-12 | NTE1914 | 3–Terminal Positive Voltage Regulator, 12V 1.0A TO-3 |
LM340T | NTE960 | 3–Terminal Positive Voltage Regulator, 5V 2.2A |
LM341 | NTE964 | 3-Terminal Positive Voltage Regulator, 8V 45mV TO-220 |
LM347 | ----- | 4-Comparators |
LM348(J,N) | NTE948 | Quad Op. Amp. |
LM350(K) | NTE970 | 3–Terminal Adjustable Positive Voltage Regulator, 1.2V to 33V, 3A |
LM358(N) | NTE928M | Low Power Dual OP-AMP |
LM361 | ----- | High Speed Differential Comparators |
LM723 | NTE956 | 3-Terminal Positive Voltage Regulator |
LM380(N) | NTE740A | Power Amplifier, Operates between 10-22V 2.5W at 8Ω 14-PIN DIP |
LM380-8 | ----- | Audio Power Amp, 700mW |
LM381(N) | NTE942 | Low Noise, Dual Preamp. |
LM383 | ----- | Audio Power Amplifier, 7w |
LM385B-Z2.5 | NTE952 | Precision 2.5V Shunt (Note: NTE says this may or may not work) |
LM386-1(A,N) | NTE823 | Low Voltage Audio Amp. 5-18V 4mA 225mW 8-PIN DIP |
LM386-2 | ----- | Low Voltage Audio Amp. 5-18V 4mA 500mW 8-PIN DIP |
LM386-3 | ----- | Low Voltage Audio Amp. 5-18V 4mA 750mW 8-PIN DIP |
LM386-4 | ----- | Low Voltage Audio Amp. 5-18V 4mA 1W 8-PIN DIP |
LM387(A,AN) | NTE824 | Low Noise, Dual-Preamp. |
LM388 | ----- | Power Amplifier, Operates between 4-15V 325mW at 8Ω 14-PIN DIP |
LM393(D,N) | NTE943M | Low Power, Low Offset, Dual Voltage Comparator |
LM394 | ----- | Super Matched NPN Transistor in an IC DIP package |
LM555 | NTE555M | Timer, Oscillator, Lower current version of NE555 |
LMC555(CN) | NTE955MC | CMOS version of the NE555, 1mW at 5V |
LM556(N,CN) | NTE978 | Dual Timer, Oscillator, Lower current version of NE556 |
LM567(C,N) | NTE832 | Tone Decoder |
LMC662 | ----- | CMOS Dual Op-Amp. |
LM723 | NTE923 | Precision Voltage Regulator (use also: uA723 or MC1723(G)) |
LM741(C,H) | NTE941 | Operational Amplifier |
LM741(CN,N) | NTE941M | Operational Amplifier |
LM741M | NTE941N | Freq. Compansated, Operational Amplifier |
LM747EN | NTE947D | Has 4-741 Chips onboard |
LM747(CN) | NTE947D | Dual Op. Amp. |
LM748(CN) | NTE975 | Op Amp. |
LM833(N) | NTE891M | Dual Audio Op. Amp. +/- 15V (Dynamic Range, Low Noise) + |
LM1084 | ----- | 5A Regulator, (use in place of LM317 which is only 1.5A) |
LM1086-33 | ----- | LDO Regulator - Low Power Version of LM317 @3.3v |
LM1117T-3.3 | ----- | LDO Regulator - Low Power Version of LM317 @3.3v |
LM1458(N) | NTE778A | Dual Operational Amplifier (use this in place of a CA3240) |
LM1830 | ----- | Fluid Detector |
LM1875(T) | NTE7143 | Audio Power Amplifier 20W 4A, 16V~60V, 5-Pin Staggered-Inline |
LM1881 | ----- | Video Sync Separator |
LM2574-Adj | ----- | Adjustable Output Voltage, Step-Down Switching Regulator 0.5A (replaces LM317) |
LM2575-5.0 | ----- | Voltage Regulator 5v 3A |
LM2576T-ADJ | ----- | Step-Down Voltage Regulator 1.23v to 37v 3A |
LM2904N | NTE928M | Low Power, Dual Op-Amp. (SO8 Case) |
LM2917(N) | NTE995 | Frequency–to–Voltage Converter |
LM2931-33 | ----- | Low Dropout Voltage Regulator 3.3v |
LM2936-3.3 | ----- | Voltage Regulator 3.3V 50mA |
LM2936Z-2.5 | ----- | VOLTAGE REGULATOR 2.5V 9uA idle - 50mA Max |
LM2936(Z)-5.0 | ----- | VOLTAGE REGULATOR 5V 9uA idle - 50mA Max (use this in place of 78L05) |
LM2940T-5.0 | NTE1951 | 3 Terminal Voltage Positive Regulator, Low Dropout Voltage, 5V, 1A... |
LM2940CT-5 | NTE1951 | 3 Terminal Voltage Positive Regulator, Low Dropout Voltage, 5V, 1A... |
LM3302(N) | NTE834 | Quad Low Power Low Offset Voltage Comparator |
LM3519 | ----- | High Frequency Boost White LED Driver w/ High-Speed PWM Brightness Control |
LM3524(N) | NTE1720 | Pulse Width Modulator (PWM), Regulator |
LM3875 | ----- | High-Performance 56W Audio Power Amplifier |
LM3876 | ----- | High-Performance Power Amplifier 56W ±30V 6A w/Mute, split-power |
LM3886(T) | NTE7197 | High-Performance 68W Audio Power Amplifier 84V, 68W @ 4ohms or 38W @ 8ohms, 28V 85mA...MAX w/ Mute |
LM3900 | ----- | Quad Op Amp |
LM3909(N) | NTE876 | LED Flasher/Oscillator (hard to find, NO longer manufactured!) |
LM3914 | NTE1508 | 10-Step Dot/Bar Display Driver, Linear Scale |
LM3915 | NTE1509 | 10-Step Dot/Bar Display Driver, Logarithmic Scale |
LM3940IT-3.3 | NTE1904 | Positive 3 Terminal Voltage Regulator, Low Dropout Voltage, 3.3v 1A |
LM4040AIZ-2.5v | ----- | Precision Micropower Shunt Voltage Reference, other voltages: -4.1 -5.0 -8.2 -10.0 TO-92 |
LM4562(A) | ----- | OP-AMP |
LM4558(N) | NTE778A | Dual Op. Amp. |
LM4780 | ----- | Overture Audio Power Amplifier, 60Wx60W Stereo or 120W Mono, 35V± 11.5A w/ Mute |
LM4819 | ----- | Boomer® 350mW Audio Power Amp, w/ Shutdown Mode 5V, 1.5mA SMT |
LM4861 | ----- | Boomer® 500mW Audio Power Amp, w/ Shutdown Mode 5V, 10mA SOP |
LM4870 | ----- | Boomer® 1.1W Audio Power Amp, w/ Shutdown Mode 2V, 15mA |
LM4871 | ----- | Boomer® 3W Audio Power Amp, w/ Shutdown Mode 5.5V, 6.5mA |
LM6361N | ----- | High Speed Op. Amp. |
LM7912 | NTE967 | Voltage Regulator, Negative, -12v 1A |
LM13600N | NTE870 | Dual Operational Transconductance Amplifier |
LM13700(N) | ----- | Dual Operational Transconductance Amplifier, with Linearizing Diodes |
LM48511 | ----- | Boomer Power Amp. Ultra-Low EMI, 3W 5V 8Ω |
LMC662 | ----- | CMOS Dual OpAmp 8V 35mA |
LMC6064 | ----- | CMOS Precision Quad Micropower Op Amp |
LMC6482 | ----- | CMOS Dual Rail-to-Rail Input / Output Op-Amp. |
LMC6485 | ----- | CMOS Quad Rail-to-Rail Input / Output Op-Amp. |
LMC6582 | ----- | Dual, Low Voltage, Rail-to-Rail, Input & Output, CMOS Op-Amp 8-Pin DIP |
LMC6584 | ----- | Quad, Low Voltage, Rail-to-Rail, Input & Output, CMOS Op-Amp 16-Pin DIP |
LME49710 | ----- | High Performance, High Fidelity Op. Amp. 5V to 12V, |
LP2950 | ----- | MicroPower, Positive Voltage Regulater, 5v |
LR8N3 | ----- | High Input, Voltage Adjustable 3-Terminal Linear Regulator 12V~450V Input, 1.20V~440V Output, 10uA |
LS4558(N) | NTE778A | Dual High-Performance OpAmp. |
LS7220 | ----- | Digital Lock IC |
LT1072 | ----- | High Efficiency Switching Regulator, 15V 1.25A -- TO220 or 8-Pin DIP |
LT1763 | ----- | MicroPower Regulators, Low Noise, LDO Input: 3.7V-15V Output: 3.3V 500ma ≡ |
LT1812CS6 | _____ | Op Amp with Shutdown, 3mA, 100MHz, 750V/us |
LTC1050 | ----- | Precision Zero-Drift OpAmp with Internal Capacitors |
LTC1442 | ----- | UltraLow Power, Single/Dual Comparator with Reference |
MA150 | NTE177 | General Purpose Silicon Rectifier |
MAX202 | ----- | 5-V Dual RS-232 Line Driver/Receiver |
MAX232(N) | NTE7142 | Dual EIA-232 Driver/Receiver (uses 1.0uF Cap)(can use ICL232IPE) |
MAX232A | ----- | Dual EIA-232 Driver/Receiver (uses 0.1uF Cap) |
MAX3232 | ----- | 3-V to 5.5-V Multi-channel RS-232 Line Driver/Receiver |
MAX7219 | ----- | Serially Interfaced, 8-Digit, LED Display Drivers |
MAX923 | ----- | UltraLow Power, Single/Dual-Supply, Comparators |
MAX9710 | ----- | Audio Power Amplifier, 3W Stereo/Mono, 5V 12mA w/ Shutdown |
MBR201-100CT | NTE6086 | Silicon Dual Shottky Rectifier, 100v 10A TO-220 |
MBR340 | NTE586 | Shottky Barrier, Fast Switching, 40V 3A |
MBR735 | NTE6083 | Shottky Barrier Rectifier, 45v 10A, 2-Lead TO-220 |
MBR1645 | NTE6081 | Shottky Barrier Rectifier, 45v 16A, 2-Lead TO-220 |
MBRS340T3 | NTE179 | Germanium PNP, Audio Power Amp., High Current Switch |
MC1310(A,P) | NTE801 | FM Stereo Demodulator |
MC1350(P) | NTE746 | TV Video IF Amplifier |
MC1458 | NTE778A | Dual Op-Amp. |
MC1466L | ----- | Precision Wide Range Voltage & Current Regulator (Motorola - no Sub. made!) |
MC1496A(N,P) | NTE973D | Balanced Modulator/Mixer |
MC1723(G) | NTE923 | IC Precision Voltage Regulator (use also: uA723 or LM723) |
MC1310 | NTE801 | FM Stereo De-Modulator |
MC3403P | NTE987 | Quad, Low Power OP Amp |
MC3479(C,P) | NTE1857 | Stepper Motor Driver 18V 7A |
MC10116(N) | ----- | Triple ECL Differential Line Receiver |
MC14106(B) | NTE40106B | 6-HEX Schmitt Trigger, Inverter |
MC14489B | ----- | Multi-Character LED Display/Lamp Driver |
MC14511B | NTE4511B | BCD-To-Seven Segment Latch/Decoder/Driver |
MC145436P | ----- | Dual-Tone Multiple Frequency Receiver (DFMF) |
MC14553 | NTE4553B | 3-Digit BCD Counter |
MC14583 | ----- | Dual Schmitt Trigger |
MC33030(P) | ----- | DC Servo Motor Controller / Driver, 1A |
MC34063(A,P) | NTE7173 | Step-Up/Down Inverting Switching Regulator, 3-40v 1.5A |
MC78M05(CP,CT) | NTE960 | Positive Voltage Regulator, 5v 1A |
MCT-2E | NTE3042 | Optoisolator, NPN Transistor Output |
MCP1702 | ----- | Microchip, CMOS LDO Regulator, 250mA Low Quiescent Current |
MCP1703 | ----- | Microchip, CMOS LDO Regulator, 250mA Low Quiescent Current |
MCP2140 | ----- | Embeds IrDA Protocol Handling and Bit Encoding/Decoding |
MCP4921 | ----- | 12-Bit DAC with SPI Interface |
MCP6021 | ----- | Microchip, Rail-To-Rail, Input/Output, Single-10Mhz Op Amp |
MCP6022 | ----- | Microchip, Rail-To-Rail, Input/Output, Dual-10Mhz Op Amp |
MCP6024 | ----- | Microchip, Rail-To-Rail, Input/Output, Quad-10Mhz Op Amp |
MEL12 | ----- | Optoisolator Photo Transistor |
MFE201 | NTE454 | MOSFET, N–Ch, Dual Gate, TV UHF/RF Amp, Gate Protected |
MFE2094 | NTE133 | N-Channel JFET Silicon Transistor, General Purpose AF Amplifier |
MJE34 | NTE153 | PNP Silicon Complementary Transistor, Audio Power Amplifier, Switch |
MJE340(K) | NTE157 | NPN Silicon Transistor, Audio Power Amp, High Voltage Converter |
MJE2955 | NTE183 | PNP Silicon Complementary Transistor, General Purpose Amp, Switch |
MJE2955K(T) | NTE332 | PNP Silicon Complementary Transistor, Audio Power Amp, Switch |
MJ2955 | NTE219 | PNP Power Transistor |
MJ3001 | NTE245 | PNP Silicon Complementary Transistor, Darlington Power Amplifier (Requires a Heatsink) |
MJ4035 | NTE249 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
MJE521 | NTE184 | NPN Silicon Complementary Transistor, Audio Power Amplifier, Switch |
MJE5976 | NTE183 | PNP Silicon Complementary Transistor, General Purpose Amp, Switch |
MJE13007(A) | NTE2312 | NPN Silicon Transistor, High Voltage, High Speed |
MJE15030 | NTE54 | NPN Silicon Complementary Transistor, High Frequency Driver for Audio Amplifier |
MJE15031 | NTE55 | PNP Silicon Complementary Transistor, High Frequency Driver for Audio Amplifier |
MJH10012 | ----- | NPN Silicon Power Darlington, 400V, 10A |
MJL21193 | NTE2671 | PNP Silicon Complementary Transistor, Silicon Perforated Emitter Technology, Audio Power Output |
MJL21194 | NTE2670 | NPN Silicon Complementary Transistor, Silicon Perforated Emitter Technology, Audio Power Output |
MK484 | ----- | AM Radio IC (replaces the ZN414 no longer made!) |
MK50240 | ----- | Top-Octave Frequency Generator |
MK50241 | ----- | Top-Octave Frequency Generator |
MK50242 | ----- | Top-Octave Frequency Generator |
MM5451 | ----- | LED Display Drivers |
MMBT100 | NTE2406 | NPN Silicon Transistor, General Purpose Amp, Surface Mount, SOT-23 |
MMBT200 | NTE2407 | PNP Silicon Transistor, General Purpose Amp, Surface Mount, SOT-23 |
MMBT5089 2N5089 | ----- | NPN General Purpose Amplifier SOT-23 or TO92 Package |
MN3007 | NTE1641 | 1024-Stage BBD for Audio Signal Delays (takes 2 to replaces an SAD-1024A) |
MN2488 | NTE2649 | NPN Silicon Complementary Darlington Power Transitor 200V 15A 130W (Use MP1620 PNP to match) |
MOC3010 | NTE3047 | Optoisolator, TRIAC Driver Output, 250v 1A |
MOC3012 | NTE3047 | Optoisolator, TRIAC Driver Output, 250v 1A |
MOC3020 | NTE3048 | Optoisolator, TRIAC Driver Output, 400v 1A |
MOC3021 | NTE3048 | Optoisolator, TRIAC Driver Output, 400v 1A |
MOC3023 | NTE3048 | Optoisolator, TRIAC Driver Output, 400v 1A |
MOC3032 | NTE3049 | Optoisolator, Zero Crossing TRIAC Driver, 15mA |
MOC3040 | NTE3097 | Optoisolator, Zero Crossing TRIAC Driver, 15mA |
MOC3041 | NTE3097 | Optoisolator, Zero Crossing TRIAC Driver, 15mA |
MOC3042 | ----- | Optoisolators Triac Driver Output, 6-Pin DIP Zero-Cross |
MOC3043 | ----- | Optoisolator, Zero Crossing TRIAC Driver, 15mA |
MOC3061-3 | ----- | Optoisolator, Zero Crossing TRIAC Driver, 16mA, 10mA, 6mA respectively, 6-Pin DIP |
MOC3063S | ----- | PhotoTriac Driver, Optocoupler, Zero-Crossing TRIAC Driver, 60mA, 6-Pin DIP, (works well with Z0103MN) |
MP1620 | NTE2650 | PNP Silicon Complementary Darlington Power Transitor 200V 15A 130W (Use MN2488 NPN to match) |
MPF102 | NTE451 | Silicon N–Channel JFET Transistor, VHF/UHF Amplifier (or use 2N5458) |
MPF-102 | NTE451 | Silicon N–Channel JFET Transistor, VHF/UHF Amplifier (or use 2N5458) |
MPS834 | NTE107 | NPN Silicon Transistor, UHF Oscillator for Tuner |
MPS3708 | NTE123AP | NPN Silicon Transistor, Audio Amp, Switch |
MPS6521 | NTE123AP | NPN Silicon Transistor, Audio Amp, Switch |
MPS6531 | NTE123AP | NPN Silicon Transistor, Audio Amp, Switch |
MPSA06 | NTE287 | NPN Silicon Complementary Transistor, High Voltage, General Purpose |
MPSA13 | NTE46 | NPN Silicon Transistor, Darlington, General Purpose Amplifier, Preamp, Driver |
MPSA14 | NTE46 | NPN Silicon Transistor, Darlington, General Purpose Amplifier, Preamp, Driver |
MPSA18 | NTE47 | NPN Silicon Transistor, High Gain, Low Noise Amp. |
MPSA42(G) | NTE287 | NPN Silicon Complementary Transistor, High Voltage, General Purpose Amplifier |
MPSA65 | NTE232 | PNP Silicon Transistor, Darlington, Amplifier, Preamp |
MPSA93 | NTE288 | PNP Silicon Complementary Transistor, High Voltage, General Purpose Amplifier |
MPSH10 | NTE229 | NPN Silicon Transistor, VHF Osc., Mixer, IF Amp |
MSA-0204 | ----- | Cascadable Silicon Bipolar MMIC Amp. DC to 1.8GHz, 5VDC, 11.0dB Gain @ 1GHz (make a nifty RF Amplifier) |
MTP3055(E,V) | NTE2396 | N-Channel, Enhancement Mode, High Speed Switch, 100V 28A, (great for Robot Wheel Driver) |
MTP3055A | NTE2390 | N-Channel, Enhancement Mode, High Speed Switch, 60V 12A |
MTP3055AFI(EFI) | NTE2340 | N-Channel, Enhancement Mode, High Speed Switch, 60V 15A |
MTP3055EL | NTE2984 | Logic-Level N-Channel, Enhancement Mode, High Speed Switch, 60V 17A |
MTP3055VL | NTE2987 | Logic-Level N-Channel, Enhancement Mode, High Speed Switch, 100V 20A |
MTP50N05(E) | NTE2395 | MOSFET N-Channel, Enhancement Mode, High Speed Switch, 60V 50A |
MTP6N60E | NTE2379 | MOSFET N-Ch, Enhancement Mode, High Speed Switch |
MR856 | NTE580 | General Purpose Silicon Rectifier, Fast Recovery, 600v |
MRF455 | NTE333 | NPN Power Amplifier Transistor. Power Supply: 12V, |
MTP6N60E | NTE2995 | MOSFET N-Channel, Enhancement Mode, High Speed Switch |
MTP3055V | NTE2396 | MOSFET N-Ch, Enhancement Mode, High Speed Switch, 20A 150W |
MUR860 | NTE598 | Silicon Rectifier Ultra Fast, 600V 8A |
MUR1550 | NTE6248 | Silicon Fast Rectifier |
MV2104 | NTE612 | Voltage Variable Capacitance Diode, (Tuning Diode) 11pF 4.0v |
MV2105 | NTE612 | Voltage Variable Capacitance Diode, (Tuning Diode) 13.2pF 4.0v |
MV2107 | NTE613 | Voltage Variable Capacitance Diode, (Tuning Diode) 22pF 4.0v |
MV2109 | NTE614 | Voltage Variable Capacitance Diode, (Tuning Diode) 33pF 4.0v |
MX-3393 | NTE1140 | Audio Power Amplifier, 12V 1A 2W Output + |
NTE1241 | NTE1241 | IC-Head Coil + Meter Driver |
NTE1497 | NTE1497 | Dual-Peak Power Meter Driver, with Auto Control |
NTE1498 | NTE1498 | Dual-Peak Power Meter Driver |
NTE1866 | NTE1866 | 5-Point LED VU-Scale, Bar-Level Meter Driver |
NTE5061A | NTE5061A | Zener Diode, 2.4V, 20mA, 1W |
NTE5062A | NTE5062A | Zener Diode, 2.5V, 20mA, 1W |
NTE5063A | NTE5063A | Zener Diode, 2.7V, 20mA, 1W |
NTE5064A | NTE5064A | Zener Diode, 2.8V, 20mA, 1W |
NTE5065A | NTE5065A | Zener Diode, 3.0V, 20mA, 1W |
NTE5066A | NTE5066A | Zener Diode, 3.3V, 76mA, 1W |
NTE134A | NTE134A | Zener Diode, 3.6V, 69mA, 1W |
NTE5067A | NTE5067A | Zener Diode, 3.9V, 64mA, 1W |
NTE5068A | NTE5068A | Zener Diode, 4.3V, 58mA, 1W |
NTE5069A | NTE5069A | Zener Diode, 4.7V, 53mA, 1W |
NTE135A | NTE135A | Zener Diode, 5.1V, 49mA, 1W |
NTE136A | NTE136A | Zener Diode, 5.6V, 45mA, 1W |
NTE5070A | NTE5070A | Zener Diode, 6.0V, 43mA, 1W |
NTE137A | NTE137A | Zener Diode, 6.2V, 41mA, 1W |
NTE5071A | NTE5071A | Zener Diode, 6.8V, 37mA, 1W |
NTE138A | NTE138A | Zener Diode, 7.5V, 34mA, 1W |
NTE5072A | NTE5072A | Zener Diode, 8.2V, 31mA, 1W |
NTE5073A | NTE5073A | Zener Diode, 8.7V, 29.5mA, 1W |
NTE139A | NTE139A | Zener Diode, 9.1V, 28.0mA, 1W |
NTE140A | NTE140A | Zener Diode, 10.0V, 25.0mA, 1W |
NTE5074A | NTE5074A | Zener Diode, 11.0V, 23.0mA, 1W |
NTE141A | NTE141A | Zener Diode, 11.5V, 22.0mA, 1W |
NTE142A | NTE142A | Zener Diode, 12.0V, 21.0mA, 1W |
NTE143A | NTE143A | Zener Diode, 13.0V, 19.0mA, 1W |
NTE144A | NTE144A | Zener Diode, 14.0V, 18.0mA, 1W |
NTE145A | NTE145A | Zener Diode, 15.0V, 17.0mA, 1W |
NTE5075A | NTE5075A | Zener Diode, 16.0V, 15.5mA, 1W |
NTE5076A | NTE5076A | Zener Diode, 17.0V, 14.75mA, 1W |
NTE5077A | NTE5077A | Zener Diode, 18.0V, 14.0mA, 1W |
NTE5078A | NTE5078A | Zener Diode, 19.0V, 13.25mA, 1W |
NTE5079A | NTE5079A | Zener Diode, 20.0V, 12.5mA, 1W |
NTE5080A | NTE5080A | Zener Diode, 22.0V, 11.5mA, 1W |
NTE5081A | NTE5081A | Zener Diode, 24.0V, 10.5mA, 1W |
NTE5082A | NTE5082A | Zener Diode, 25.0V, 10.0mA, 1W |
NTE146A | NTE146A | Zener Diode, 27.0V, 9.5mA, 1W |
NTE5083A | NTE5083A | Zener Diode, 28.0V, 9.0mA, 1W |
NTE5084A | NTE5084A | Zener Diode, 30.0V, 8.5mA, 1W |
NTE147A | NTE147A | Zener Diode, 33.0V, 7.5mA, 1W |
NTE5085A | NTE5085A | Zener Diode, 36.0V, 7.0mA, 1W |
NTE5086A | NTE5086A | Zener Diode, 39.0V, 6.5mA, 1W |
NTE5087A | NTE5087A | Zener Diode, 43.0V, 6.0mA, 1W |
NTE5088A | NTE5088A | Zener Diode, 47.0V, 5.5mA, 1W |
NTE5089A | NTE5089A | Zener Diode, 51.0V, 5.0mA, 1W |
N8281(F,N) | NTE74177 | 35-MHz Presettable Decade & Binary Counters / Latches (SN74177N) |
NE5532(N,P) | NTE778A | Dual Low-noise OP-AMP 3-20V 10mA (fairly quite and works well for a Sound Console) |
NE5534(AN,N) | NTE894M | Low-Noise OP-AMP 3-20V 10mA (if you want very low noise, then us a AD797) |
NE555(N,V) | NTE955M | Single-Timer, Oscillator, 2V-15V |
(use 7555, ICM7555, LMC555 or TS555CN, uses less current) | ||
NE556 | NTE978 | Dual-Timer, Oscillator |
NE558 | NTE926 | Quad-Timer, Oscillator |
NE565 | NTE989 | General Purpose Phase-Lock-Loop (PLL) or SCA Decoder |
NE566 | ----- | Voltage Controlled Oscillator |
NE567 | NTE832 | Tone Decoder |
NE602(N,FE) | NTE7164 | Double-Balanced Mixer and Oscillator |
NJM2035 | ----- | Stereo Modulator |
NJM2902 | NTE897 | Quad, Low Power OP Amp |
----- | NTE1690 | Telephone DTMF Dialer |
----- | NTE5463 | Silicon-Controlled Rectifier (SCR), 200v 10A |
OA47 | NTE110A | Germanium Diode, General Purpose |
OA71(C) | NTE109 | Germanium Diode, Fast Switching General Purpose |
OA73(C) | NTE109 | Germanium Diode, Fast Switching General Purpose |
OA81(C) | NTE109 | Germanium Diode, Fast Switching General Purpose |
OA91(A) | NTE109 | Germanium Diode, Fast Switching General Purpose |
OED-EL-1L2 | ----- | Lumex IR Photodetector 38-kHz, (perfect match for the PNA4602M) |
OP176 | ----- | Bipolar/JFET, Audio Operational Amplifier |
OPA124P | ----- | Low Noise Precision Difet, Op Amp ±12 V |
OPA690 | ----- | Single Wideband, Voltage Feedback OpAmp with Disable |
OPA2132P | ----- | High-Speed FET-Input Operational Amplifier 2/\.5V to 18V 50 pA Max |
OPA2134PA | ----- | SoundPlus(TM), High Performance Audio Op-Amp's |
OPA2690 | ----- | Dual Wideband, Voltage Feedback OpAmp with Disable |
OPA3690 | ----- | Triple Wideband, Voltage Feedback OpAmp with Disable |
P6KE15A | NTE4920 | Surge Clamping, Transient Overvoltage Suppressor Unidirectional, Vr 12.80v |
P6KE27A | NTE4934 | Surge Clamping, Transient Overvoltage Suppressor Unidirectional, Vr 23.10v |
PAM8610 | ----- | 10Wx2 8 Ohm, Stereo Class-D Audio Power Amp. W/ DC Volume Control |
PC817 | NTE3098 | Optoisolator Phototransistor, w/NPN Transistor Output |
PCM2702 | ----- | 16-Bit Stereo Digital-to-Analog Converter with USB 1.0 Interface |
PCM2902 | ----- | Stereo Audio Codec w/ USB Interface and SPDIF I/O Terminal |
PGA2310 | ----- | Stereo Audio Volume Control 16-Pin DIP |
PMP4201 | ----- | NPN/NPN Matched Double Transistors |
PN100(A) | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch (use 2N3904) |
PN200(A) | NTE159 | PNP Silicon Transistor, Audio Amplifier, Switch (use 2N3906) |
PN2222(A) | NTE123A | NPN Silicon Complementary Transistors, Audio Amp, Switch (use 2N2222) |
PNA4602(M) | ----- | IR Photodetector 38-kHz, (perfect match for the OED-EL-1L2 or TSOP34338) |
PT2399 | ----- | Echo / Surround / Delay, Processsor |
PTC205 | NTE125 | General Purpose Silicon Rectifier 1000V 1A |
Q4004LT | NTE5646 | TRIAC, Internally Triggered, 600V 10A |
QT113 | ----- | Charge-Transfer Touch Sensor, Active-Low |
QT113H | ----- | Charge-Transfer Touch Sensor, Active-High |
RC4136N | NTE997 | Quad Op. Amp. |
RC4151(N) | NTE890 | Voltage to Frequency Converter |
RD4.7E | NTE5009A | ZENER Diode, 4.7v 0.5W |
RD-5A | NTE135A | ZENER Diode, 1 Watt, 1.5v, 200mA |
REF102 | ----- | Precision Voltage Reference 10V |
RFP30N06LE | NTE2985 | N-Channel Enhancement Mode, High Speed Switch, Logic Level MOSFET 60V 30A |
RL207 | NTE156 | General Purpose Silicon Rectifier 700V 2A |
RPM7138 | ----- | Remote Control IR Receiver Module |
S10VB20 | NTE5313 | Single Phase Bridge Rectifier, 600V 8A |
S106D | NTE5457 | Silicon Controlled Rectifier (SCR), 400V 4A |
S106Y | NTE5455 | Silicon Controlled Rectifier (SCR), 200V 4A |
S1B0102 | NTE116 | General Purpose Silicon Rectifier, 600V 1A |
S2003LS1 | NTE5426 | Silicon Controlled Rectifier (SCR), 400V 10A, with Sensitive Gate, Isolated |
SA602AN | NTE7164 | Double−Balanced Mixer & Oscillator (formerly NE405) |
SA605D | ----- | High Performance, Low Power, Mixer FM IF System |
SAD-1024A | ----- | (use 2 MN3007 in place of this device) |
SB140 | NTE585 | Silicon Rectifier Diode, Schottky Barrier, Fast Switching |
SB540 | NTE573 | Schottky Barrier Diode, 60V 5A |
SC141D | NTE5608 | TRIAC 400V 8A |
SFH309 | ----- | NPN Phototransistor, Clear |
SFH309FA | ----- | NPN Phototransistor, Dark (Black) |
SFH409 | ----- | GaAs Infra-Red Emitter, Diode |
SG3524(B,N) | NTE1720 | Pulse Width Modulator (PWM), Regulator |
SI7661 | ----- | CMOS Voltage Inverter, (like ICL7662) |
SK100 | NTE2403 | PNP Silicon Complimentary Transistor, Low Noise, UHF/VHF Amplifier (NOT an exact replacement, and is Surface Mounted!) |
SK7661 | NTE1281 | 50W AMP. |
SL100 | NTE108 | NPN Silicon Transistor, High Frequency Amplifier |
SL-100 | NTE108 | NPN Silicon Transistor, High Frequency Amplifier |
SM5162 | ----- | 312 RF Encoder |
SM5172 | ----- | 312 RF Decoder |
SN754410 | ----- | Push-Pull 4-Channel Driver with Diodes, 800mA (can use L293D) |
SN76477 | ----- | Sound Generator |
STA7360 | ----- | Bridge Power Amplifier 20W or Stereo 10W x 10W 18V w/ Mute |
STP16NF06 | ----- | N-Channel MOSFET |
SY32PT | ----- | LED Photo Transistors |
T106D1 | NTE5457 | Silicon Controlled Rectifier (SCR), 400v 4 Amp Sensitive Gate, TO-202 |
T1C206D | NTE5608 | TRIAC 400v 8A (replaces C106D, but with higher current rating) |
T2301PD5 | NTE5652 | TRIAC 400v 2.5A |
T6411M | NTE5697 | TRIAC High Current, 600v 30A |
TA2020 | ----- | Audio Power Amplifier, 2x20W 4Ω 13.8V 4A |
TA7222(AP) | NTE1278 | Audio Power Amplifier, 5.8W Dual BTL - 15W 18V 4.5A 10-Pin |
TA7240(AP) | ----- | Audio Power Amplifier, 5.8W Dual BTL - 15W 18V 4.5A12-Pin |
TA7642 | ----- | AM Radio IC |
TA8251AH | ----- | Audio Power Amplifier 18x4 Watts, Standby-Switch, Muting - 9V-18V |
TBA820M | NTE1294 | Audio Power Amplifier, 3v to 16v, 1.5A, 1.2W Output w/ +9vdc & 8 Ohm Spkr. |
TC962 | ----- | High Current Charge Pump, DC-To-DC Converter (similar to ICL7662) |
TCA5550 | ----- | Stereo Sound Control System w/ Tone Control |
TCS230 | ----- | Programmable Color Light-To-Frequency Converter |
TDA1013(A,B) | NTE1852 | Audio Power Amplifier, w/ DC Volume Control, 4W, 35V, 3A |
TDA1029 | ------- | Dual Signal Sources Switch, 4 Mutually Switchable Inputs, supply: 6V to 23V 3.5mA |
TDA1074 | NTE7072 | Dual DC Controlled Potentiometer - Use for controlling Audio or Bass / Treble Circuits |
TDA1514(A,AU) | NTE7118 | Audio Power Amplifier, 50W 70V 8A, 9-Pin Inline |
TDA1516(Q) | NTE1802 | Audio Power Amplifier, Stereo 2x12W, 18V 4A, 13-Pin Staggered-Inline |
TDA1524(A,AN) | NTE1803 | Audio Control, Stereo Pre-Amp, w/ Treble & Bass, 18-Pin DIP |
TDA1553 | ----- | Audio Car Amplifier, Stereo 2x22W, Loudspeaker Protection, 3-State Mode Switch, 12V 4A, 13-Pin Staggered-Inline |
TDA1554(Q) | NTE7114 | Audio Power Amplifier, Stereo 2x22W 18V 4A w/ Mute/Standby, 17-Pin Staggered-Inline |
TDA1562Q | ----- | High-Efficiency Power Amplifier, w/ Diagnostic Facility, 70W, 14.4V, 17-Pin Staggered-Inline |
TDA1905 | NTE7000 | Audio Amplifier, 4V to 30V, 2.5A @14v and 8Ω gives 5W, w/ Muting, 16-Pin DIP |
TDA1910 | ----- | Audio Power Amplifier, 10W 24V 3A, w/ Muting, 11-Pin Staggered-Inline |
TDA2002 | ----- | Audio Power Amplifier, 8W, 18V, 5-Pin Staggered-Inline |
TDA2003(H,V) | NTE1288 | Audio Power Amplifier, 10W @ 2Ω or 6W @ 4Ω, 12V, (For small elec. devices, or car), 5-Pin Staggered-Inline |
TDA2005(M,BM) | NTE1396 | 20 Watt Bridge Booster for Car Radio, 18V 3.5A, 11-Pin Staggered-Inline |
TDA2009(A) | NTE7105 | Audio Power Amplifier, Stereo 2x10W, 28V 3.5A, 11-Pin Staggered-Inline |
TDA2030(A,V) | NTE1380 | Audio Power Amplifier, 14W 18V 3.5A, 5-Pin Staggered-Inline |
TDA2040(V) | NTE1376 | Audio Power Amplifier, 22W 20V 4A, 5-Pin Staggered-Inline |
TDA2050(V) | NTE7169 | Audio Power Amplifier, 32W 25V 5A, 5-Pin Staggered-Inline |
TDA2616 | ----- | Audio Power Amplifier, Stereo 2x12W Dual-Supply 12V 2A, w/ Mute, 9-Pin Inline |
TDA2822(M) | NTE7155 | Dual,(Stereo), Low–Voltage Power Amplifier, 1.8-15V 1A 1.4W, 8-Pin DIP (Good replacement for LM386) |
TDA4935 | ----- | Stereo/Bridge AF Amplifier, 2x15W Stereo, 30W Mono, 32V 2.8A, 9-Pin Inline |
TDA6103(Q) | ----- | Triple Video Output Amplifier |
TDA7000 | ----- | F.M. Radio Circuit IC |
TDA7052(N) | NTE7051 | BTL, (Bridge-Tied-Load) Mono Audio Amplifier, 1W 18V, 8-Pin DIP (Good replacement for LM386) |
TDA7053 | ----- | Stereo Power Amplifier 2x1W, 6V, 16-Pin DIP |
TDA7056(U) | NTE7052 | BTL, (Bridge-Tied-Load) Mono Audio Amplifier, 3W 18V, 100mA 9-Pin Inline |
TDA7056B | ----- | BTL, (Bridge-Tied-Load) Mono Audio Amplifier, w/ DC Volume Control, 5W 18V,100mA 9-Pin Inline |
TDA7205 | ----- | Audio Amplifier, Mono 1W (sorry, don't have Pinout on this one) |
TDA7231(A) | NTE7184 | Audio Amplifier, Mono Audio Amplifier, 1.6W 16V 1A, 8-Pin DIP (Good replacement for LM386) |
TDA7240 | ----- | Bridge Amplifier, 20W 18V 3.5A w/ Mute/Standby, 7-Pin Staggered-Inline |
TDA7050 | ----- | Stereo Amplifier Low Power, Low Voltage ≡ |
TDA7263 | NTE7146 | Stereo Amplifier, 2x12W, 35V 2.5A w/ Mute/Standby, 11-Pin Staggered-Inline |
TDA7265 | NTE7198 | Stereo Amplifier, 2x25W, 25V 4.5A w/ Mute/Stand-By, 11-Pin Staggered-Inline |
TDA7269 | ----- | Stereo Amplifier, 2x10W, w/ Mute |
TDA7293(V) | NTE7186 | DMOS Audio Amplifier, Mono Audio Amplifier, 100W 60V 10A w/ Mute/Standby, 15-Pin Staggered-Inline |
TDA7294(V) | NTE7165 | DMOS Audio Amplifier, Mono Audio Amplifier, 100W 50V 10A, w/ Turn-On Delay, 15-Pin Staggered-Inline |
TDA7295 | ----- | DMOS Audio Amplifier, Mono Audio Amplifier, 80W 80V 6A w/ Mute/Standby, 15-Pin Staggered-Inline |
TDA7296 | NTE7165 | DMOS Audio Amplifier, Mono Audio Amplifier, 100W 50V 10A, w/ Turn-On Delay, 15-Pin Staggered-Inline |
TDA7297 | Stereo Audio Amplifier, 15Wx15W 20V 2A, w/ Standby/Mute, 15-Pin Staggered-Inline | |
TDA7375 | ----- | Dual/Quad Power Amplifiers, 2x35W, 4Ω 12V 4A, 15-Pin Staggered-Inline |
TDA7377(H,V) | ----- | Dual/Quad Power Amplifiers, 2x20W, 4Ω 14V 4A, 15-Pin Staggered-Inline |
TDA7386 | NTE7163 | Quad-Bridge Amplifier, 4x40W, 18V 4.5A, 25-Pin Staggered-Inline |
TDA7396 | ----- | 45W/2Ω Bridge Amplifier with Diagnostic Facility, 28V, Mute |
TDA7481 | ----- | 18W x 18W Dual BTL Class-D Amplifier |
TDA7490 | ----- | Stereo Class-D Amplifier, 25W+25W, |
TDA7492 | ----- | 50W x 50W Dual BTL Class-D Amplifier |
TDA7494 | ----- | 10W x 10W Dual BTL Class-D Amplifier |
TDA8703 | ----- | 8-Bit High-Speed, ADC Converter has LOTS of features! |
TEA5767HL | ----- | Single Chip FM Stereo Radio 3-Wire |
TEA5767HN | ----- | Single Chip FM Stereo Radio 3-Wire / I2C |
TEA5768HL | ----- | Single Chip FM Stereo Radio I2C |
TFDU4300 | ----- | Infrared Transceiver Module |
TI416 | NTE123AP | NPN Silicon Transistor, Audio AMP, Switch |
TI419 | NTE123AP | NPN Silicon Transistor, Audio AMP, Switch |
TIC47 | NTE5404 | SCR 200v 0.8A |
TIC206D | NTE5608 | TRIAC "Non-Isolated", 400v 8A |
TIC206M | NTE5609 | TRAIC 600v 8A |
TIC225M | NTE5609 | TRIAC 400V 8A |
TIC226D | NTE5635 | TRAIC 400v 10A |
TIL061 | ----- | Low Power Single JFET OpAmp. |
TIL111 | NTE3042 | Optoisolator, NPN Transistor Output |
TIL119 | NTE3044 | Optoisolator, NPN Darlington Transistor Output |
TIP24 | NTE152 | NPN Silicon Complementary Transistor, Audio Power Amp., Switch |
TIP31C | NTE291 | NPN Silicon Complementary Transistor, Medium Power Amp, Switch |
TIP32A | NTE292 | PNP Silicon Complementary Transistor, Medium Power Amp, Switch |
TIP33(B) | NTE390 | NPN Power Silicon Complementary Transistor, General Purpose |
TIP34(B) | NTE391 | PNP Power Silicon Complementary Transistor, General Purpose |
TIP41A | NTE196 | NPN Silicon Complementary Transistor, Audio Power Output and Medium Power Switching |
TIP42(A) | NTE197 | PNP Silicon Complementary Transistor, Audio Power Output and Medium Power Switching |
TIP42C | NTE332 | PNP Silicon Complementary Transistor, Audio Power Amp, Switch |
TIP102 | NTE2343 | NPN Darlington Power Amp, Switch |
TIP107 | NTE2344 | PNP Darlington Power Amp, Switch |
TIP111 | NTE261 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
TIP116 | NTE262 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
TIP117 | NTE262 | PNP Silicon Complementary Transistor, Darlington Power Amplifier |
TIP120 | NTE261 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
TIP121 | NTE261 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
TIP122 | NTE261 | NPN Silicon Complementary Transistor, Darlington Power Amplifier |
TIP2955 | NTE393 | PNP Silicon Complementary Transistor, General Purpose |
TIP3055 | NTE392 | NPN Silicon Complementary Transistor, General Purpose 3A - (TO-218, or use 2N3055) |
TIP3055T | NTE331 | NPN Silicon Complementary Transistor, Audio Power Amp, Switch |
TIS34 | NTE132 | N-Channel JFET, VHF Amp, Mixer |
TLE2425 | ------ | Precision Virtual Ground 2.5V, Draws on 170uA ≡ |
TL062(C,CP) | NTE889M | Low current BIFET Dual Op-Amp |
TL064 | ----- | Quad, Low-Noise, JFET Input, Operational Amplifier |
TL071 | NTE857M | Low-Noise, JFET Input, Operational Amplifier |
TL072 | NTE858M | Dual, Low-Noise, JFET Input, Operational Amplifier |
TL074(CN) | NTE859 | Quad, Low Noise, JFET Input, Operational Amplifier |
TL081(N,CP) | NTE857M | Low Noise, J-FET-Input, Op Amp. |
TL082 | NTE858M | Dual, Low–Noise, JFET–Input, Operational Amplifier |
TL084 | NTE859 | Quad, Low Noise, JFET Input, Operational Amplifier |
TL431(C) | NTE999 | Adjustable Precision Shunt Regulator |
TL494(C,N,CN) | NTE1729 | Pulse Width Modulation (PWM) Control Circuit |
TL499A | ----- | Wide-Range Power-Supply Controller |
TL7726 | ----- | Hex Clamping Circuits |
TLC372CP | NTE943M | Low Power, Low Offset, Dual Voltage Comparator |
TLC431C | NTE999 | Adjustable Precision Shunt Regulator 2.5v to 36v |
TLC548(IP) | ----- | 8-Bit ADC 45.5-KSPS Converters with Serial Control, DIP |
TLC549 | ----- | 8-Bit ADC 40-KSPS Serial Out, Digital/Parallel Out, Low Power, Single Channel |
TLC555(CD) | NTE955MC | CMOS 1-Timer, Oscillator Circuit CMOS version of the NE555 (works 2-15v) |
TLC556(C,CN,CP) | NTE978C | CMOS 2-Timer, Oscillator Circuit's CMOS version of the NE556 (works 2-15v) |
TLC2201 | ----- | LinCMOS Low-Noise Precision, Rail-To-Rail Output Op Amp. |
TLC226x | ----- | Op Amp, Advanced LinCMOS, Rail-to-Rail, very quiet, x=2 Dual, x=4 Quad |
TLC2272 | ----- | Dual Low-Noise Rail-To-Rail Operational Amplifier |
TLP115A | ----- | Photocoupler IRED & Photo-IC |
TLP3042 | NTE3097 | Optpisolator, Zero-Crossing TRIAC Driver |
TLP521-1 | NTE3098 | NPN Phototransistor, NPN Transistor Output |
TLV431 | ----- | LOW-VOLTAGE ADJUSTABLE PRECISION SHUNT REGULATOR (outputs a 1.24v reference) |
TO-3 | NTE405 | 2-Piece PCB Mounting Kit |
TO-3 | NTE413 | Insulator Kit |
TO-220 | NTE406A | Heaksink Clip |
TO-220 | NTE422 | Insulator Kit |
TOP224YN | NTE7192 | PWM Switch for TV, Monitors and Audio Amps, 85-265VAC, 45W |
TOP225YN | NTE7193 | PWM Switch for TV, Monitors and Audio Amps, 100/115/230VAC, 100W |
TP5088 | ----- | DTMF Generator for Binary Data |
TPA3110 | ----- | 2x15W per channel Amplifier, 8V~26V, 32mV |
TPA3116D2 | ----- | 2x50W Per Channel Amplifier, 21V |
TPA3118D2 | ----- | 2x30W Per Channel Amplifier, 21V |
TPA3130D2 | ----- | 2x15W Per Channel Amplifier, 21V |
TPA3122 | ----- | 2x15W per channel Amplifier, 10V~30V, 50mV |
TS2012 | ----- | 2x2.8W per channel Class-D Amplifier, 2.5-5V, 200mA, QFN20 package |
TS5A5159 | ----- | 1-Ohm SPDT Analog Switch |
TS555CN | NTE955MC | CMOS 555 Timing Circuit + |
TSOP1730 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 30Khz |
TSOP1733 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 33Khz |
TSOP1736 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 36Khz |
TSOP1737 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 37Khz |
TSOP1738 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 38Khz |
TSOP1740 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 40Khz |
TSOP1756 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 56Khz |
TSOP34338 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 38Khz |
TSOP38238 | ----- | Photo IR Recv. Modules for PCM Remote Control Systems 38Khz |
uA723 | NTE923 | IC Precision Voltage Regulator (use also: MC1723(G) or LM723) |
uA741 | NTE941M | IC Op Amp. |
uA78S40 | ----- | Universal Switching Regulator Subsystem |
UCN5804B | ----- | BiMOS II, Unipolar Stepper-Motor, Translator / Driver |
UF4003 | NTE587 | Silicon Diode, Ultra-Fast Switch, 200V 1A |
UF4004 | NTE574 | Silicon Diode, Ultra-Fast, 400v 1A |
ULN2001A | ----- | Seven Darlington Arrays |
ULN-2003A | NTE2013 | 7-Channel Darlington Array/Driver, w/ Diode built-in, Common Cathode |
ULN2004(A) | NTE2014 | 7-Channel Darlington Array/Driver, w/ Diode built-in, Common Cathode |
ULN2203(A,AN) | NTE2013 | 7-Channel Darlington Array/Driver 30V 500mA |
ULN2803(A,AN) | NTE2018 | 8-Channel Darlington Array/Driver 30V 600mA |
uPC575C2 | NTE1140 | Audio Power Amplifier, 12V 1A 2W Output |
VN10KM | NTE491T | MOSFET, N-Ch, Enhancement Mode, High Speed Switch (or VN66AF) |
VN10L | NTE491 | MOSFET, N−Ch, Enhancement Mode, High Speed Switch (or 2N7000) |
W-01 | NTE5304 | Silicon Bridge Rectifier, 400v, 1.5amp |
W-005 | NTE166 | Single Phase Bridge Rectifier, 100V, 2A |
W005 | NTE5304 | Silicon Bridge Rectifier, 400v, 1.5amp |
Z0103MN | ----- | Triac 600V, 1A, (works well with: MOC3063S) |
ZHCS2000 | ----- | Silicon High-Current Schottky Barrier Diode, 40V 2A, (use with Bright LEDs) |
ZN414 | ----- | AM Radio IC (replaced by MK484) |
ZSCT1555 | ----- | Precision Single Cell Timer, will work as low as 0.9v, 74uA |
ZSR500 | ----- | 5V Fixed Positive Local Voltage Regulator SOT-223 or TO92 Package |
ZTX108 | NTE199 | NPN Silicon Transistor, Low Noise, High Gain Amplifier |
ZTX300 | NTE123AP | NPN Silicon Transistor, Audio Amplifier, Switch |
ZTX320 | NTE108 | NPN Silicon Transistor, High Frequency Amplifier, (use for FM Xmit.) |
ZTX451 | NTE2657 | NPN Silicon Complementary Transistors, Medium Power |
ZTX458 | ----- | NPN High Voltage Transistor, Medium Power, 400v |
ZTX550 | NTE2658 | PNP Silicon Complementary Transistors, Medium Power |
ZTX653 | NTE2657 | NPN Silicon Complementary Transistors, Medium Power |
ZTX751 | NTE2658 | PNP Silicon Complementary Transistors, Medium Power |
ZTX753 | NTE2658 | PNP Silicon Complementary Transistors, Medium Power |
ZTX851 | ----- | NPN SILICON PLANAR MEDIUM POWER, HIGH CURRENT |
ZTX857 | ----- | NPN SILICON PLANAR MEDIUM POWER, HIGH CURRENT |
ZTX1053 | ----- | NPN SILICON PLANAR MEDIUM POWER, HIGH GAIN |
ZVN2106(A) | ----- | N-Channel Enhancement Mode, Vertical DMOS FET |
ZXSC100 | ----- | Single Cell DC-DC Step-up Converter, (great for Hi-Intensity LEDs) |
ZXT13N20DE6 | ----- | NPN Silicon Low Saturation Switching Transistor, 20V, 4.5A (great for Hi-Ten. LEDs) |
ZY18 | NTE5077A | ZENER 18v 1W |
26 Page Views [1]
